Oil pump YCB-G
electricself-priminggear

oil pump
oil pump
Add to favorites
Compare this product


Characteristics

Media
oil
Operation
electric
Priming
self-priming
Technology
gear
Domain
industrial
Applications
process, cooling, conveying
Other characteristics
for heating
Flow

25 m³/h (882.8667 ft³/h)

Pressure

5 bar (72.519 psi)

Description

YCB-G series insulation gear pump overview: The YCB-G series insulation gear pump is an external gear pump, and the tooth shape is composed of a circular arc and a sine curve. The conveying medium is wide, and the output flow and pressure are stable. The pump body is provided with thermal insulation jacket for heating, heat preservation and cooling. When the viscosity of the conveying medium is greater than 1500cSt, the deceleration transmission mode should be adopted The YCB-G type heat preservation gear pump is suitable for conveying heavy oil without solid particles and at temperatures not higher than 300 degrees Celsius, asphalt, resin, detergent, rubber and other solidified media at room temperature, and is suitable for outdoor installation in cold regions and the occasions requiring heat preservation during the process. Model description: YCB---------Circular arc gear pump 25----------Capacity m3/h 0.6--------Pressure 0.6MPa G-----------Thermal insulation type
