Flat plug K0452 series
threadedpolyamidethermoplastic

Flat plug - K0452 series - HEINRICH KIPP WERK GmbH & Co. KG - threaded / polyamide / thermoplastic
Flat plug - K0452 series - HEINRICH KIPP WERK GmbH & Co. KG - threaded / polyamide / thermoplastic
Flat plug - K0452 series - HEINRICH KIPP WERK GmbH & Co. KG - threaded / polyamide / thermoplastic - image - 2
Add to favorites
Compare this product

Characteristics

Form
flat
Type
threaded
Material
polyamide, thermoplastic
Function
drain, magnetic
Product applications
oil, insert
Other characteristics
screw-in
Diameter

Min.: 20 mm
(0.787 in)

Max.: 42 mm
(1.654 in)

Operating temperature

100 °C
(212 °F)

Description

Material:Thermoplastic polyamide 66. Ferrite permanent magnet.Version:Black. Flat seal asbestos-freeNote:The magnetic effect of the screw plug attracts iron particles in the oil. Screwing the plug into the drain outlet diminishes possible damage to mechanical components.Temperature range:Temperature resistant with oil up to 100°C.Drawing reference: 1) flat seal 2) magnet
