Screw with hexagonal head K0380 series
hex socketsteel

Screw with hexagonal head - K0380 series - HEINRICH KIPP WERK GmbH & Co. KG - hex socket / steel
Screw with hexagonal head - K0380 series - HEINRICH KIPP WERK GmbH & Co. KG - hex socket / steel
Screw with hexagonal head - K0380 series - HEINRICH KIPP WERK GmbH & Co. KG - hex socket / steel - image - 2
Screw with hexagonal head - K0380 series - HEINRICH KIPP WERK GmbH & Co. KG - hex socket / steel - image - 3
Screw with hexagonal head - K0380 series - HEINRICH KIPP WERK GmbH & Co. KG - hex socket / steel - image - 4
Screw with hexagonal head - K0380 series - HEINRICH KIPP WERK GmbH & Co. KG - hex socket / steel - image - 5
Screw with hexagonal head - K0380 series - HEINRICH KIPP WERK GmbH & Co. KG - hex socket / steel - image - 6
Screw with hexagonal head - K0380 series - HEINRICH KIPP WERK GmbH & Co. KG - hex socket / steel - image - 7
Screw with hexagonal head - K0380 series - HEINRICH KIPP WERK GmbH & Co. KG - hex socket / steel - image - 8
Add to favorites
Compare this product

Characteristics

Head
with hexagonal head
Drive type
hex socket
Materials
steel
Diameter

Max.: 24 mm
(0.945 in)

Min.: 4 mm
(0.157 in)

Length

Max.: 94.7 mm
(3.73 in)

Min.: 9.9 mm
(0.39 in)

Description

Material:Screw carbon steel. Ball ball-bearing steel.Version:Screw grade min. 10.9, black. Ball hardened, bright.Note:Form A with full ball is used when a clean, polished contact surface is required. Surfaces which are not flat and parallel can be firmly clamped or supported with Form B with flattened ball, the movable ball can adapt itself up to 9°.Drawing reference: Form A: full ball Form B: flattened ball Form BV: flattened ball, rotation lock Form F: serrated flattened ball Form FV: serrated flattened ball, rotation lock

Catalogs

K0380
K0380
3 Pages
