Integrated zero-point clamping system M-52X52(3131G)

compactquicksquare

Overview
Provides clearance between the machine bed and tooling to optimize space for tool feed in multi-axis and single-piece machining processes.

Applications

• Suitable for multi-axis machining and single-piece formed processes.
• Improves accessibility for complex workpiece geometries and reduces machining interference.

Available models / Sizes

• M-52x52(3131G) — 150×116×60 mm
• M-96x96(8222G) — 192×156×60 mm
• M-52x52(3133G) — 150×116×100 mm
• M-96x96(8226G) — 192×156×100 mm

SPECIFICATIONS (H=60)
Unit: mm
Model | L×W×H | Pull Studs | Weight (kg)
M-52x52(3131G) | 150x116x60 | M-52x52PS / M-96x96PS | 7.9
M-96x96(8222G) | 192x156x60 | M-96x96PS | 13.5

SPECIFICATIONS (H=100)
Unit: mm
Model | L×W×H | Pull Studs | Weight (kg)
M-52x52(3133G) | 150x116x100 | M-52x52PS / M-96x96PS | 12.9
M-96x96(8226G) | 192x156x100 | M-96x96PS | 22.5

Technical details

• Denomination: RECTANGULAR RISER -G
• Manufacturer / Brand: HOMGE
• Available variants: M-52x52(3131G), M-96x96(8222G), M-52x52(3133G), M-96x96(8226G)
• Heights: H = 60 mm and H = 100 mm
• Typical dimensions: 150×116×60 mm; 192×156×60 mm; 150×116×100 mm; 192×156×100 mm
• Compatible pull studs: M-52x52PS, M-96x96PS
• Weights by model: 7.9 kg, 13.5 kg, 12.9 kg, 22.5 kg
• Unit for dimensions: mm
• Main use: raise workpiece to provide tool clearance and reduce interference; integration with zero-point clamping systems
• Includes product images and technical drawings on the product page
