Electric forklift J2.0-3.5XTLG

ride-onindooroutdoor

Overview
The J2.0-3.5XTLG series is a 4-wheel electric counterbalance forklift designed for demanding indoor and outdoor applications. Powered by a lithium‑ion battery pack, the truck combines long run times, opportunity charging capability and a low-noise drive train with an optional weatherproof cabin for sheltered outdoor use.

Key benefits

• Reduced environmental impact with zero on-site emissions
• Lower Total Cost of Ownership through reduced maintenance and energy use
• Larger standard battery capacity for extended runtime
• Enhanced productivity from responsive drive and steering
• Improved operator comfort with ergonomic, weatherproof cabin option

Li-ion solution summary
The zero‑maintenance lithium‑ion battery supports opportunity charging, eliminates battery topping‑up and reduces downtime. A 5‑year battery warranty is provided and a 154V battery option delivers ICE‑like performance with higher travel and lift speeds and improved gradeability.

Features and operator benefits

• Spacious, weatherproof operator cabin for outdoor protection and comfort
• Low‑noise drive train for quieter working environments
• Opportunity charging capability to fit busy operational schedules
• Responsive traction motor and smooth steering for precise handling
• Pneumatic tyres for improved traction and ride on rough surfaces

Industry sectors

• Paper & Packaging
• Metals
• Automotive & Transport manufacturing
• Building materials
• Agriculture
• Chemicals & Plastics

Models and specifications (table)
Model | Load Capacity | Load Centre | Lift Height | Turning Radius | Battery Capacity
J2.0XTLG | 2000 kg | 500 mm | 3000 mm | 2290 mm | 153.6V / 228Ah (V/Ah)
J2.5XTLG | 2500 kg | 500 mm | 3000 mm | 2350 mm | 153.6V / 228Ah (V/Ah)
J3.0XTLG | 3000 kg | 500 mm | 3000 mm | 2430 mm | 153.6V / 228Ah (V/Ah)
J3.5XTLG | 3500 kg | 500 mm | 3000 mm | 2500 mm | 153.6V / 228Ah (V/Ah)

Technical specifications

• Series / Model designation: J2.0-3.5XTLG
• Capacity range: 2000–3500 kg
• Load centre: 500 mm (all listed models)
• Standard lift height shown: 3000 mm
• Turning radius by model: 2290–2500 mm
• Battery: Lithium‑ion, typical capacity 153.6V / 228Ah; 154V option available
• Zero on-site emissions and low-noise operation
• Designed for indoor and outdoor use with pneumatic tyres and optional weatherproof cabin
