Electric forklift J5.0-7.0XTLG

ride-onfor the construction industryfor warehouse

Overview
The J5.0-7.0XTLG is a 4-wheel electric counterbalanced forklift designed for indoor and outdoor industrial operations. It features a 352V/228Ah lithium battery with side charging, water-cooled drive components and a permanent magnet drive system to maximise system efficiency and uptime.

Key features

• 4-wheel counterbalanced layout for stable load handling
• Permanent magnet synchronous motor and high-efficiency controller
• Lithium battery with side charging to simplify battery access
• IPX4 protection for operation in wet conditions
• Automatic battery heating function to manage temperature during discharge and prior to charging

Reliability and durability

• Proven structural design for both indoor and outdoor applications
• Extensive environmental testing to validate durability
• Water-cooled motors and controllers to maintain optimal operating temperatures
• BMS and controller with leakage detection for battery and system safety

High efficiency and performance

• High-efficiency permanent magnet motor and controller system
• System working efficiency up to 95%
• Up to 20% reduction in energy consumption compared with conventional systems
• Integrated BMS and leakage detection to protect battery and electronics

Ergonomics and operator comfort

• Ergonomically optimized operator compartment and multiple seat options
• Informative colour display with selectable performance modes
• Wide-view mast for improved forward visibility
• Large tyres and increased ground clearance for uneven surfaces

Models and specifications (excerpt)
Model | Load Capacity | Load Centre | Lift Height | Turning Radius | Battery Capacity
J5.0XTLG6 | 5000 kg | 600 mm | 3000 mm | 3250 mm | 352V/228Ah (V/Ah)
J6.0XTLG6 | 6000 kg | 600 mm | 3000 mm | 3300 mm | 352V/228Ah (V/Ah)
J7.0XTLG6 | 7000 kg | 600 mm | 3000 mm | 3360 mm | 352V/228Ah (V/Ah)

Technical specifications

• Model series: J5.0-7.0XTLG
• Capacity range: 5000–7000 kg
• Load centre: 600 mm
• Standard lift height shown: 3000 mm
• Turning radius: 3250–3360 mm depending on model
• Battery: 352V / 228Ah lithium, side charging
• Motor: Permanent magnet synchronous motor; water-cooled motors and controllers
• Efficiency: up to 95% working efficiency; up to 20% energy reduction
• Protection: IPX4 waterproof rating
• Battery management: BMS with leakage detection; automatic heating function
• Operator features: ergonomic compartment, multiple seat options, colour display with performance modes
• Intended use: suited for industries such as logistics/3PL, beverage, construction materials, chemicals/plastics, timber, metals and automotive
