Three-phase electric energy meter EM513084

DIN railRS-485residential

The EM513084 is a Class B three-phase smart meter designed for accurate measurement of both active and reactive energy. Operating at 3x230/400V and 5(100)A, this meter supports bi-directional energy metering and complies with EN50470-1/3 standards. It features an IR communication port adhering to EN62056 (IEC1107) protocol for local data access and is designed for easy DIN rail installation. Introduction The EM513084 is a Class B three-phase smart meter designed for accurate measurement of both active and reactive energy. Operating at 3x230/400V and 5(100)A, this meter supports bi-directional energy metering and complies with EN50470-1/3 standards. It features an IR communication port adhering to EN62056 (IEC1107) protocol for local data access and is designed for easy DIN rail installation. Key Features Accuracy Class: Class B Metering Functionality: Supports both active and reactive energy measurement, as well as bi-directional (forward and reverse) metering. Communication: Integrated IR communication port compliant with EN62056 (IEC1107) protocol. Standards Compliance: Meets EN50470-1/3 requirements. Installation: DIN rail mounting. Comply with RE test, EMi compatible
