Universal testing machine WE-600D
bendingcompressiontensile

Universal testing machine - WE-600D - Jinan Hensgrand Instrument Co.,Ltd - bending / compression / tensile
Universal testing machine - WE-600D - Jinan Hensgrand Instrument Co.,Ltd - bending / compression / tensile
Universal testing machine - WE-600D - Jinan Hensgrand Instrument Co.,Ltd - bending / compression / tensile - image - 2
Universal testing machine - WE-600D - Jinan Hensgrand Instrument Co.,Ltd - bending / compression / tensile - image - 3
Add to favorites
Compare this product
Go to the Jinan Hensgrand Instrument Co.,Ltd website for more information

Characteristics

Test type
bending, compression, universal, tensile, for IZOD testing, push-deformation, shock, calibration, temperature, constant load, tension, shearing, wear, fatigue, performance load, stability, creep, torsion, life cycle, creep-in-compression, tension/compression, hardness, break force, durability, tensile strength, pressure, static load, quality, compression resistance, stress test, tensile stress relaxation, endurance, performance, mechanical
Operating mode
computer-controlled, fully-automatic, semi-automatic, PLC-controlled
Test material
material, for springs, for plastics, for electronic components, hose, for cement, for leather, for high-strength bolts, for geotextiles, for plastic sheets, for cardboard boxes, for plastic pipes, for rebar, for round bars, for rubber, for flexible materials, for building materials, concrete, for plastic film, for touchscreens, for rope, for non-wovens, for wire, for foam, for paper, for textiles, for packaging, for composite materials, for cables, for sheet metal, for pipes, for bars and tubes, adhesive, for adhesive tape, for engine components, for pipes, for chains
Sector
for research and development, for laboratory, industrial, for railway applications, for the automotive industry, for quality control, for the pharmaceutical industry, for telecommunications, for the construction industry, for workshops, for the electronics industry, for the beverage industry, for the aerospace industry, for medical applications, for the optical industry, for the packaging industry, for the petroleum industry, for the food industry, for the aeronautical industry
Technology
digital, hydraulic, electro-hydraulic, dynamic
Configuration
vertical
Other characteristics
precision, static, high-stability, 4-column, high-acceleration, high-speed, rugged, with touchscreen, stainless steel, pendulum, stand-alone, routine test, biaxial

Description

Hydraulic Universal Tensile Testing Machine adopts hydraulic loading, Digital Display, easy and convenient to operate. It is mainly used to execute the tension, compression, bending, flexural etc. test for metal materials. Attached with simple accessories and devices, it can be used to test wood, concrete, cement, rubber, and so on.It is very suitable for making test to different metal or nonmetal materials under high toughness and hardness against extreme big loading force. Standards: ISO6892, BS4449,ASTM C39,ISO75001, ASTM A370, ASTM E4, ASTM E8 and BSEN standards. Specifications Max. Load(kN) 300 600 1000 Load accuracy Class 0.5 Measuring range 1％～100％ Displacement Resolution 0.01mm Load resolution Capacity/500,000WE-300/600/1000D Digital Display Hydraulic Universal Testing Machine Tensile space(mm) 780 900 950 Compression space(mm) 550 650 700 Distance berween two columns 485 485 500 Piston stroke(mm) 200 200 200 Clamping Method Hydraulic Automatic Clamp Power Supply 3-phase, AC380V, 50Hz (Can Be Customized)
