Compression testing machine WAW-300D

universaltensilebending

Metal Material Universal Testing Machine adopts hydraulic loading, Computer Display, easy and convenient to operate. It is mainly used to execute the tension, compression, bending, flexural etc. test Standards: ISO6892, BS4449,ASTM C39,ISO75001, ASTM A370, ASTM E4, ASTM E8 and BSEN standards. Application: Metal Material Universal Testing Machine adopts hydraulic loading, Computer Display, easy and convenient to operate. It is mainly used to execute the tension, compression, bending, flexural etc. test for metal materials. Attached with simple accessories and devices, it can be used to test wood, concrete, cement, rubber, and so on.It is very suitable for making test to different metal or nonmetal materials under high toughness and hardness against extreme big loading force. Specifications: Structure - 4 columns and 2 screws Control way - Constant stress uniform deformation constant displacement three closed loop control and program control dealing Max.load (kN) - 300kN Load accuracy - ≤±0.5% Load range - 1%-100%FS Load resolution - 1/500000 Deformation Measurement Range - 1%～100%FS Deformation accuracy - ≤±0.5% Displacement resolution (mm) - 0.0025 Displacement error - ≤±0.5% Max.piston stroke(mm) - 250 Max piston moving speed - 0-100mm/min stepless speed adjusting Crosshead lifting speed - 200mm/min Max. tension test space - 780mm (can customize) Max.Compression Test Space - 550mm (can customize) Column clearance(mm) - 485 Clamping method - Hydraulic clamp Round specimen clamping range (mm) - Φ10-Φ20,Φ20-Φ32, (Φ4-Φ10 Optional ) Flat specimen clamping range (mm) - 0-15 (15-30 Optional)
