Piston compressor 3L-4L

reciprocatingairelectrically-powered

Overview
The 3LBA-46S-M300AX is a tank-mounted reciprocating compressor system driven by a mid-compact 3L twin-cylinder piston compressor. It supplies oil-free compressed air across a range of pressures and flows for industrial applications requiring consistent high pressure. The basic (uncovered) configuration is available with multiple tank sizes and riser mount options to simplify installation and maintenance. Corrosion-resistant internal components and a design with no wearing parts minimize contamination and extend service intervals.

Highlights

• Durable and oil-free: Oil-free design delivers clean, contaminant-free air for sensitive processes
• High pressure capability: Operates up to 50 PSI (3.45 Bar) for demanding, consistent-pressure applications
• Tank-mounted: Tank sizes ranging from 2 to 60 gallons available
• Riser mount options: Elevates the compressor for easier access during installation and maintenance

Product Identifiers

• Item #: 3LBA-46S-M300AX
• Series: Piston Systems
• Description: Reciprocating compressor (tank system)

Technical specifications

• Model / SKU: 3LBA-46S-M300AX
• Series: Piston Systems
• Description: Reciprocating compressor (tank system)
• HP: 0.33
• Amps (60Hz): 6.6 A
• Weight: 30.2 lb (14 kg)
• Open Flow (60Hz): 3 CFM (85 LPM)
• Flow @ Max Pressure (60Hz): 2 CFM (56.6 LPM)
• Voltage (60Hz): 115 V
• Max Pressure: 50 PSI (3.45 Bar)
• Phase: Single Phase
• Regulatory: cULus
• Country of Origin: USA
• Sound Level: 75 dBA
• Dimensions (in): 15.5 L x 12.35 W x 8.11 H
• Dimensions (mm): 393.7 L x 313.7 W x 206.0 H
