Plasma cutting machine Plasma-Jet TrueCut 2040 H

for metalsheet metalCNC

Overview
The Plasma-Jet TrueCut 2040 H is a heavy‑duty plasma cutting system engineered for production and single‑part manufacture of complex components. Designed for continuous multi‑shift operation, it accepts a range of Hypertherm plasma sources and a wide set of options for tailored process configurations.

Highlights

• Independent, rigid cutter table for high positional accuracy
• ProNest LT nesting software included for optimized production
• Prepared for HYPERTHERM plasma sources (optional configurations)
• Designed for high productivity in multi‑shift environments
• Extensive optional modules for customised solutions (multiple torches, oxy‑fuel, tube processing, beveling)

Construction

• Stand‑alone steel cutter table to isolate thermal and mechanical influences from the gantry
• Table prepared for dust/fume extraction with electro‑pneumatic suction flaps on active cutting segments
• Robust frame and components selected for industrial continuous use

Transmission and drives

• Dynamic AC servo drives (Panasonic) on all axes with maintenance‑free, zero‑backlash planetary gears
• Low‑wear helical rack-and-pinion drives sized for continuous operation
• Linear guideways on all axes for long life and smooth motion (X/Y guide widths 20/30 mm)

Cutting head

• Z axis with ball‑screw transmission and servo‑driven automatic torch height control (THC)
• Quick‑coupling for rapid cutter‑head exchange to reduce downtime
• Use of stored cutting parameters in the controller for optimal cut quality
• Optimised traverse speeds for fine contours and tight radii; optional 5‑axis head and tube cutter available

Control

• CNC controller: Hypertherm EDGE® Connect
• ProNest LT nesting software delivered as standard
• On‑screen operator console (Soft OpCon) and CutPro® Wizard for guided setup; integrated diagnostic tools
• Interfaces with plasma and torch height control systems

Plasma source options (selection)

• Maxpro 200 — near‑burr‑free cutting of unalloyed steel up to ~20 mm (piercing/production capacities higher depending on process)
• XPR 170 — plunge cut max. 40 mm; severing cut max. 60 mm (excellent X‑Definition quality for thin to medium materials)
• XPR 300 — plunge cut max. 50 mm; severing cut max. 80 mm (higher speeds and extended capability)

Working area
Cutting width: 2,000 mm
Cutting length: 4,000 mm
Table height: 700 mm
Table load capacity: 520 kg/m2
Rapid feed: 18,000 mm/min
Plasma source: Hypertherm options


Measures and weights
Weight: 4,100 kg


Notes

• All specified cutting and piercing depths depend on material, cutting process and guide system
• Extensive optional equipment available (oxy‑fuel heads, tube systems, extraction/filtration, Hypertherm source configurations, software modules such as beveling or collision avoidance)

caractéristiques / spécifications techniques

• Model / commercial name: Plasma-Jet TrueCut 2040 H
• Brand: KNUTH
• SKU: 144015
• Working area (W x L): 2,000 mm x 4,000 mm
• Table height: 700 mm
• Table load capacity: 520 kg/m2
• Rapid feed: 18,000 mm/min
• Plasma source: Hypertherm options (Maxpro 200, XPR 170, XPR 300)
• CNC: Hypertherm EDGE® Connect with Phoenix® built‑in software
• Standard software: ProNest LT included
• Z axis: ball‑screw transmission with automatic torch height control (THC)
• Drive technology: Panasonic AC servo drives, planetary gears
• Table features: independent, rigid steel construction; prepared for fume extraction/filter system
• Suitable for: multi‑shift industrial operation
• Net machine weight: 4,100 kg
