Plasma cutting machine Plasma-Jet TrueCut 3060 H

for metalsheet metalCNC

Description
The Plasma-Jet TrueCut 3060 H machines are specialised plasma cutting systems for batch or single-piece production of complex parts. Designed for high loads and multi-shift operation, the series integrates Hypertherm plasma platforms and industrial-grade components. A wide range of optional equipment allows customised solutions such as multiple torches, oxy-fuel heads, mitre cutting or pipe processing units.

Highlights

• Independent cutter table for high positional accuracy
• Powerful ProNest LT nesting software for production optimisation
• Prepared for use with Hypertherm plasma sources (optional)
• Engineered for high productivity and continuous multi-shift operation
• Extensive modular options for tailored configurations

Working area (table)
Cutting width: 3.000 mm
Cutting length: 6.000 mm
Table height: 700 mm
Table load capacity: 520 kg/m2
Rapid feed: 18.000 mm/min
Plasma source family: Hypertherm (selectable)

Measures and weights
Weight (approx.): 9.500 kg

Product details
Construction

• Stand-alone cutter table in rigid steel construction for high load capacity
• Isolated table eliminates thermal and mechanical influences on the cutting drive
• Table prepared for dust/extraction systems; equipped with electro-pneumatically actuated suction flaps for efficient fume removal on the active cutting segment

Transmission and drives

• Dynamic AC servo drives (Panasonic) on all axes with maintenance-free, zero-backlash planetary gearboxes
• Low-wear helical rack-and-pinion drives designed for continuous use
• Linear guideways on all axes sized for long life and smooth motion (X/Y guide widths: 20/30 mm)
• Machine structure and component selection enable reliable multi-shift operation

Cutting head

• Z-axis with ball screw transmission and servo-driven automatic torch height control (THC)
• Quick-coupling for cutter head enables fast head exchanges to reduce tooling time
• Use of stored cutting parameters in the controller to achieve optimum cuts
• Optimised bed speed for fine contours and tight radii
• Available options include 5-axis cutter head, tube cutting units and more

Control

• Hypertherm CNC controller – EDGE Connect
• ProNest LT nesting software supplied as standard for nesting and production optimisation

Plasma source options and cutting capability notes

• Maxpro 200: burr‑free cutting in mild steel up to ~20 mm; production plunge cut up to 32 mm; severing up to 75 mm
• XPR 170: plunge cut up to 40 mm; severing up to 60 mm
• XPR 300: plunge cut up to 50 mm; severing up to 80 mm

Note
All stated cutting and piercing depths depend on material, cutting technology and guide system configuration.

Technical characteristics / specifications

• Model: Plasma-Jet TrueCut 3060 H
• Working area (W x L): 3.000 mm x 6.000 mm
• Table height: 700 mm
• Table load capacity: 520 kg/m2
• Rapid feed: 18.000 mm/min
• Standard plasma family: Hypertherm (options: Maxpro 200, XPR 170, XPR 300, XPR 460 variants)
• CNC: Hypertherm EDGE Connect with Phoenix built-in and ProNest LT
• Weight (approx.): 9.500 kg
• Optional equipment: oxy-fuel heads, tube cutting systems (3.000 / 6.000 mm), 5-axis bevel cutting, extraction/filter prep, various Hypertherm consoles and starter consumable kits
