Plasma cutting machine Plasma-Jet TrueCut K 2040

for metalsheet metalCNC

Description
The Plasma-Jet TrueCut K 2040 is a plasma cutting system designed for production and one-off manufacturing of complex parts. Fitted with Eckelmann CNC control and options for Kjellberg plasma sources, the machine is engineered for heavy-duty, multi-shift operation and extensive option tailoring (multiple torches, oxy-fuel heads, mitre cutting, tube-processing units).

Highlights

• Freestanding cutter table for thermal and mechanical decoupling and high accuracy
• Eckelmann CNC with EtherCAT for full cutting process control
• Designed for high productivity and continuous multi-shift use
• Wide range of options for customer-specific configurations

Working area (table)
Cutting width: 2.000 mm
Cutting length: 4.000 mm
Table height: 700 mm
Table load capacity: 520 kg/m2
Rapid feed: 18.000 mm/min
Plasma source: Kjellberg (various models available)

Measures and weights
Weight: 4.100 kg

Product details
Construction

• Stand-alone cutter table in rigid steel construction for high load capacity
• Separate table eliminates thermal and mechanical influences on the gantry and guides
• Table prepared for dust collection with electro-pneumatic suction flaps for local fume extraction

Transmission and drives

• Dynamic AC servo drives (Panasonic) on all axes with maintenance-free, zero-backlash planetary gears
• Low-wear helical rack-and-pinion drives designed for continuous operation
• Linear guideways on all axes sized for long life and smooth motion; guide widths on X/Y axes: 20/30 mm
• Machine structure and component selection engineered to support multi-shift operation

Cutting head

• Z axis with ball screw transmission and servo-driven automatic torch height control
• Quick-coupling for fast cutter head exchanges
• Use of stored cutting parameter databases in the controller to achieve optimum cuts
• Optimised axis speeds for fine contours and tight radii
• Available options: 5-axis cutter head, tube cutter and additional accessories

Control

• Eckelmann CNC controller (E°EXC / IBE family)
• Eckelmann IBE software delivered as standard (nesting and cutting functions)

Plasma source options (examples)

• Smart Focus 130 – max cutting 40 mm, plunge 25 mm, recommended 1–32 mm
• Smart Focus 170 – max cutting 50 mm, plunge 30 mm, recommended 1–35 mm
• Smart Focus 200 – max cutting 60 mm, plunge 30 mm, recommended 1–40 mm
• Smart Focus 300 – max cutting 80 mm, plunge 40 mm, recommended 1–60 mm
• Smart Focus 400 – max cutting 100 mm, plunge 50 mm, recommended for stainless steel 1–70 mm
• Q 1500 – max cutting 60 mm, plunge 30 mm, recommended 0.5–40 mm
• Q 3000 – max cutting 80 mm, plunge 50 mm, recommended 0.5–60 mm

Standard equipment / Examples of included items

• Table prepared for filter system (automatic closure control)
• Panasonic servomotors and drives
• Automatic torch height control from Eckelmann
• Cutting torch with magnetic coupling and crash sensor
• Eckelmann CNC unit (E°EXC 880 / E°CUT ECO) with 19" touchscreen option
• A-module from Beckhoff, laser pointer, Eckelmann IBE software cncCUT Nest

Optional equipment / Examples

• Upgrades to Kjellberg Q series plasma sources (Q1500, Q3000, Q4500 etc.)
• Smart Focus plasma sources (130 / 170 / 200 / 300 / 400) with automatic gas console
• Oxy-fuel cutter heads (Tanaka and others)
• Tube cutting systems, additional tube supports and extensions
• 5-axis chamfering and tube cutting systems, bevel devices, consumables starter sets
• Dust vacuum and filter systems

Technical specifications

• Cutting width: 2.000 mm
• Cutting length: 4.000 mm
• Table height: 700 mm
• Table load capacity: 520 kg/m2
• Rapid feed: 18.000 mm/min
• Plasma source: Kjellberg (various models available)
• Weight: 4.100 kg
• CNC controller: Eckelmann with IBE nesting software
