Wastewater pump Amaline
slurryelectricsubmersible

wastewater pump
wastewater pump
wastewater pump
Add to favorites
Compare this product


Characteristics

Fluid
for wastewater, slurry
Operation
electric
Priming
submersible
Technology
propeller
Mobility
stationary
Domain
industrial, for water treatment
Applications
discharge, sewage, treatment, recirculation
Voltage
400 V, 380 V
Protection level
ATEX
Other characteristics
horizontal mount, bi-directional, sensor
Flow

Min.: 0.1 m³/h
(3.53147 ft³/h)

Max.: 6,700 m³/h
(236,608.26703 ft³/h)

Pressure

16 bar
(232.06 psi)

Head

Min.: 0.1 m
(0'03" )

Max.: 3.5 m
(11'05" )

Power

Min.: 1.25 kW
(1.7 hp)

Max.: 27 kW
(36.71 hp)

Fluid temperature

Min.: 2 °C
(35.6 °F)

Max.: 40 °C
(104 °F)

Description

Wet-installed horizontal propeller pump with submersible motor, equipped with direct drive or spur gear, ECB propeller with rigid, fibre-repellent blades, bolt-free connection to the discharge pipe. Explosion-proof version available. Main Applications Recirculating activated sludge from the nitrification to the denitrification stage of activated sludge tanks Economic handling of stormwater, river water, surface water and polder water at low heads Generating flow in water bodies Benefits Perfectly protected by absolutely water-tight cable gland protecting the motor against moisture Motor monitored by temperature sensors to prevent it from overheating Easy to install Double safety by two bi-directional mechanical seals with oil reservoir filled with environmentally friendly oil Leakage chamber between oil chamber and gear unit for high reliability Optional: leakage sensor in leakage chamber available for non-explosion-proof version
