DESIGN
• These are end suction, single stage centrifugal pumps. These
three pumps, YNM 525, YNM 825 and YNM 1531 are used for
flow rates ranging between 50 and 1250 gpm.
• The main pump dimensions are compatible with DiN 24256.
The pump flanges are designed according to UL standards
ANSI/ASME B16 Class 250.
• The pump performances are compatible with UL standards.
• The single suction, closed type impeller is dynamically
balanced against the thrust by use of back wear rings.
• Shaft leak prevention is provided by 5 unit soft packing
according to UL448 requirements.
• The parts inside the pumps that are in contact with water,
such as bolts or bolt screws, are made of non-corrosive materials
Flow Range 50 – 1250 gpm (10 – 280 m³/h)
Head Range 80 – 155 psi (55 – 110 m)
Operating Pressure 14 bar
Working Temperature 0 – 60°C
Speed 2900 rpm
Suction Flange 3” – 8”
Discharge Flange 2” – 6”
