Automatic strapping machine SoniXs MS-6 KR

for PP-PET strapsfor logisticsfor the packaging industry

Overview
The SoniXs MS-6 KR automatic strapping machine is designed to secure bulky products such as white goods and furniture for transport. Its side-positioned sealing unit enables operation at low conveyor heights and protects the sealing unit from dust and debris. Custom frame sizes and conveyor-height options are available to meet production requirements.

Key features

• Automatic strapping machine
• SoniXs ultrasonic sealing system (Standard-6)
• Suitable for PP and PET strap
• Side sealing unit for low conveyor heights

Standard features

• Controlled flap frame with magnetic locking and opening
• Frame sizes graduated in 400 mm increments
• Hinged stainless steel table
• 4 swivel castors, all lockable
• SoniXs ultrasonic sealing system (Standard-6)
• Integration into any processing line possible
• Optimum accessibility and tool-free disassembly of belt path components
• Dispenser can be mounted variably
• Strap tension adjustable via the control panel
• Simple machine operation via digital display in the control panel
• Manual strapping release via push button in the control panel
• Infinitely variable rotating control panel (0 - 180°)
• Extremely low energy consumption
• CE marking including Declaration of Conformity

Options

• Manual strapping release via flexible foot switch
• Core dispenser Ø 406 mm (option for PET)
• Signal light (LED)
• Preliminary end-of-strap query with signal to the control unit
• Signal exchange via 16-pin contact socket
• Fully automatic reel change with double dispenser
• Special conveyor height options

Consumables & production
Mosca manufactures polypropylene (PP) and polyester (PET) strapping at its central facility in Muckental since 2008 on a modern production line. Paper strapping is also available as a recyclable alternative produced from renewable raw materials.

Applications / Use
Intended for securing bulky products (white goods, furniture) for transport. Offers low conveying-height solutions and can be integrated into processing and packaging lines. Custom frame sizes and configurations are available.

Technical specifications

• Performance: up to 24 strappings/min (example: frame size 1200 x 2000 mm; actual speed depends on configuration)
• Frame size (width): 400 - 2,400 mm in 400 mm increments
• Frame size (height): 1,200 - 2,400 mm in 400 mm increments (freely combinable up to max frame circumference 8,000 mm)
• Conveyor height (standard): from 170 mm to 565 mm; optional extension from 170 mm to 910 mm
• Strapping material - PP: width 12 mm; thickness 0.55 mm - 0.80 mm
• Strapping material - PET: width 9.50 mm - 12 mm; thickness 0.54 mm
• Strap coil dispenser core diameter: 200 mm (optional 406 mm for PET)
• Strap coil core length: 190 mm (optional 150 mm for PET)
• Mains voltage: 100 - 240 V, 50/60 Hz, 1L+N+PE (other voltages on request)
• Power consumption: approx. 0.2 kW (depending on configuration)
• Weight: from approx. 250 kg to 500 kg (depending on configuration)
• Sealing: SoniXs ultrasonic sealing system (Standard-6)
• Mobility: 4 lockable swivel castors for positioning
