Automatic strapping machine SoniXs P7-T

ultrasonicstrapping machinefor polypropylene straps

Product overview
The SoniXs P7-T is an automatic strapping machine in a tabletop design (Model T). It features a compact, easily accessible frame with strap coil loading from the front or the side, allowing use in confined spaces, manual operation or integration into automated production lines. A narrow-product unit is available for the 500 × 400 mm frame for particularly slim items.

Applications and model
Tabletop machine for polypropylene (PP) straps; suitable for packaging stations, end-of-line integration and manual workstations. Available frame sizes cover a wide range of product dimensions; a dedicated narrow-product unit is provided for the 500 × 400 mm frame.

Key features

• Automatic strapping with SoniXs ultrasonic sealing (Standard-7)
• Suitable for PP straps, width 5–12 mm, thickness 0.40–0.63 mm
• Compact, space-saving tabletop design
• Strap coil change from front or side for flexible positioning
• Strap tension adjustable from the control panel; selectable soft strapping for delicate packages
• Performance up to 58 strappings/min (depending on configuration)
• Narrow-product unit available for 500 × 400 mm frame

Standard equipment

• SoniXs ultrasonic sealing system (Standard-7)
• Optimum accessibility and tool-free disassembly of belt path components
• Folding tables for improved access
• Strap end query with strap remainder ejection
• Extremely low energy consumption and stand-by function
• Manual strapping release via 2 fixed foot switches or continuously rotatable control panel (0–180°)
• 4 castors, 2 lockable; signal light (LED)
• CE marking including Declaration of Conformity

Options

• Pneumatic hold-down device
• 4 swivel castors, 2 lockable (option)
• Signal exchange via 16-pin contact socket
• Table extension 90 mm per side
• Lowering suspension H = 730–835 mm (front/rear or outwards)
• Height adjustment 920–1,025 mm
• Castors in table top
• Manual strapping release via additional flexible foot switch
• Automatic strapping release via light sensor

Technical specifications

• Performance: up to 58 strappings/min (depending on configuration)
• Frame sizes (W × H): 500 × 400 mm; 600 × 600 mm; 800 × 400 mm; 800 × 800 mm; 1,000 × 800 mm; 1,250 × 600 mm; 1,250 × 1,000 mm; 1,650 × 600 mm
• Strapping material (PP): width 5 mm – 12 mm; thickness 0.40 mm – 0.63 mm
• Strap coil dispenser core diameter: 200 mm; core length: 190 mm
• Mains voltage: 100–240 V, 50/60 Hz, 1L+N+PE (other voltages on request)
• Power consumption: approx. 0.2 kW (depending on configuration)
• Weight: approx. 190 kg (without options)
• Model type: Tabletop (T); sealing: SoniXs Standard-7 ultrasonic; coil loading: front or side

Advantages for industry

• Compact footprint and flexible coil loading simplify workstation layout
• Tool-free maintenance and folding tables reduce downtime
• Low energy consumption and stand-by function reduce operating costs
• Selectable soft strapping and adjustable tension protect sensitive products
