ProfiNet indicator PN350 touchMATRIX®

process7-segmentwith touch screen

touchMATRIX® PROFINET fieldbus indicator The fieldbus indicator PN350 can record, calculate, evaluate, display and pass on process data. The interfaces also enable the configuration and scaling of the device during the transmission of status information during operation. It is ideally suited as an on-site indicator with a resistive touchscreen, multi-color graphic display (red, green, yellow) and multiple display options. • Multi-function display with PROFINET interface • Operating modes for displaying two process values and links of the two values (1+2, 1-2, 1x2, 1:2) • PROFINET Device Conformance Class B • Dual Port Ethernet with integrated switch • 5 control inputs with HTL PNP (3 inputs configurable) • Bright and high-contrast display with event dependent color variations • Emulation of a 7-segment display inclusively icons and units • Intuitive and easy parameterization by plain text and touch screen • 3.78 x 1.89 inch (96 x 48 mm) norm panel housing and IP65 protection • Optional switching outputs Available options: PN350: Basic unit with PROFINET-interface • Option AC: Power supply 115 … 230 VAC • Option AO: 16 bit analog output, 4 control outputs, serial RS232 interface • Option AR: 16 bit analog output, 4 control outputs, serial RS485 interface • Option CO: 4 control outputs, serial RS232 interface • Option CR: 4 control outputs, serial RS485 interface • Option RL: 2 relay outputs Options can be combined
