Rotary vane pump P series
for chemicalsfor food productsoil

Rotary vane pump - P series - MOUVEX - for chemicals / for food products / oil
Rotary vane pump - P series - MOUVEX - for chemicals / for food products / oil
Rotary vane pump - P series - MOUVEX - for chemicals / for food products / oil - image - 2
Rotary vane pump - P series - MOUVEX - for chemicals / for food products / oil - image - 3
Rotary vane pump - P series - MOUVEX - for chemicals / for food products / oil - image - 4
Rotary vane pump - P series - MOUVEX - for chemicals / for food products / oil - image - 5
Rotary vane pump - P series - MOUVEX - for chemicals / for food products / oil - image - 6
Rotary vane pump - P series - MOUVEX - for chemicals / for food products / oil - image - 7
Rotary vane pump - P series - MOUVEX - for chemicals / for food products / oil - image - 8
Rotary vane pump - P series - MOUVEX - for chemicals / for food products / oil - image - 9
Rotary vane pump - P series - MOUVEX - for chemicals / for food products / oil - image - 10
Rotary vane pump - P series - MOUVEX - for chemicals / for food products / oil - image - 11
Rotary vane pump - P series - MOUVEX - for chemicals / for food products / oil - image - 12
Add to favorites
Compare this product

Characteristics

Technology
rotary vane
Fluid
for chemicals, for food products, oil
Operation
electric
Priming
self-priming
Mobility
stationary
Domain
industrial, for the chemical industry, for oil industry applications, for marine applications
Applications
transfer, discharge, cooling, suction, unloading, adjustment, replacement, suction
Material
stainless steel, cast iron, steel, metal
Fluid specification
for high-viscosity products
Other characteristics
with mechanical seals, heating
Flow

15 m³/h, 25 m³/h, 40 m³/h, 65 m³/h, 110 m³/h
(529.72 ft³/h, 882.86667 ft³/h, 1,412.58667 ft³/h, 2,295.45334 ft³/h, 3,884.61334 ft³/h)

Pressure

12 bar
(174.045 psi)

Fluid temperature

250 °C
(482 °F)

Length

450 mm, 561 mm, 586 mm, 664 mm
(18 in, 22 in, 23 in, 26 in)

Width

323 mm, 435 mm, 455 mm, 483 mm
(12.72 in, 17.13 in, 17.91 in, 19.02 in)

Height

327 mm, 402 mm, 412 mm, 505 mm
(12.87 in, 15.83 in, 16.22 in, 19.88 in)

Weight

41 kg, 69 kg, 75 kg, 175 kg
(90.39 lb, 152.12 lb, 165.35 lb, 385.81 lb)

Description

Rotary Vane Pumps have been specifically designed to handle highly viscous products up to 110 m3/h (12 bar), including non-lubricating, abrasive and corrosive liquids. Thanks to their excellent volumetric characteristics, these pumps guarantee reduced energy consumption. In addition, P Series pumps feature easy and economical maintenance. Performance and Specifications Performance Constant high performance Excellent volumetric characteristics Thanks to automatic adjustment, the performance characteristics remain constant throughout time Easy and economical maintenance P series vane pumps can be dismantled without disconnecting the suction and discharge lines. Pump reassembly requires no special positioning Replacement parts are extremely competitive The pump is capable of running in forward or reverse Options Pump body: cast iron, steel or stainless steel Mouvex seals, single or double-standard mechanical seals or packed gland Vanes equipped with polymer or metal, either free or with push rods Single or double bypass Heating or cooling shells Electric heating
