PTFE rod Rulon® 488sheetrolltubular
Add to favorites
Compare this product
Characteristics
- Shape
- sheet, rod, tubular, roll
- Protection level
- abrasion-resistant, wear-resistant
- Other characteristics
- chemical-resistant, for high-temperature applications, low-friction, low water absorption, for cryogenic applications
- Length
Min.: 610 mm
(24.02 in)Max.: 3,000 mm
(118.11 in)- Width
Min.: 80 mm
(3.15 in)Max.: 1,000 mm
(39.37 in)- Diameter
120 cm
(47.24 in)- Thickness
Min.: 0.08 mm
(0.003 in)Max.: 6 mm
(0.236 in)
Description
Overview
Rulon® 488 is a dull turquoise filled PTFE material developed for use on painted and abrasive surfaces. It offers broad chemical resistance and improved load and wear performance compared with related Rulon® grades, making it suitable for demanding bearing and sealing applications including veneer dryer bearings and hydrogen/natural gas compressors.
Materials and Processing
The compound is produced by compression molding and delivered molded or precision-machined from high-performance PTFE and filled PTFE composites.
Performance & Service Conditions
Very good wear resistance in dry environments. Service temperature range: -240°C to +288°C. Mechanical strength: 6.9 MPa. Friction coefficient: 0.10–0.30. Max PV (dry/lub): 0.35 MPa·m/s.
Typical Offerings
Applications
Standard Specifications
Material: dull turquoise fluoropolymer, engineered filled PTFE. Manufacturing: compression molding; precision machining as required. Dimensions: rods & tubes φ1.2 m × L3 m; sheets L610 mm × W80 mm; tapes W1 m × T 0.08–6 mm.
Features & Benefits
Technical specifications
Rulon® 488 is a dull turquoise filled PTFE material developed for use on painted and abrasive surfaces. It offers broad chemical resistance and improved load and wear performance compared with related Rulon® grades, making it suitable for demanding bearing and sealing applications including veneer dryer bearings and hydrogen/natural gas compressors.
Materials and Processing
The compound is produced by compression molding and delivered molded or precision-machined from high-performance PTFE and filled PTFE composites.
Performance & Service Conditions
Very good wear resistance in dry environments. Service temperature range: -240°C to +288°C. Mechanical strength: 6.9 MPa. Friction coefficient: 0.10–0.30. Max PV (dry/lub): 0.35 MPa·m/s.
Typical Offerings
- Automatically molded bearings and components
- Sleeve, flanged and thrust bearings
- Stamped and formed seals
- Extruded shapes
- Machined parts and molded shapes
Applications
- Pumps, mixers and compressors
- Appliances and insulators
- Linear slides, pipe supports and wear bands
- Environments: steam, wet, dry and vacuum; also suitable for hydrogen and natural gas compressors
Standard Specifications
Material: dull turquoise fluoropolymer, engineered filled PTFE. Manufacturing: compression molding; precision machining as required. Dimensions: rods & tubes φ1.2 m × L3 m; sheets L610 mm × W80 mm; tapes W1 m × T 0.08–6 mm.
Features & Benefits
- Improved abrasion resistance versus related Rulon® grades
- Higher load capacity compared with Rulon® J
- Low friction coefficient and low moisture uptake
- Dimensional stability in presence of chemicals
- Suitable for extreme temperatures and dry operating conditions
Technical specifications
- Material family: PTFE / filled PTFE composite
- Color: dull turquoise
- Temperature range: -240°C to +288°C
- Mechanical strength: 6.9 MPa
- Friction coefficient: 0.10 - 0.30
- Max PV (dry/lub): 0.35 MPa·m/s
- Manufacturing: Compression molding; molding and precision machining
- Available forms: rods & tubes, sheets, tapes (dimensions above)
