PTFE rod Rulon® W2sheetrolltubular
Add to favorites
Compare this product
Characteristics
- Shape
- sheet, rod, tubular, roll
- Protection level
- immersible, abrasion-resistant, wear-resistant
- Other characteristics
- chemical-resistant, low-friction, low water absorption
- Length
Max.: 3,000 mm
(118.11 in)Min.: 610 mm
(24.02 in)- Width
Max.: 1,000 mm
(39.37 in)Min.: 80 mm
(3.15 in)- Diameter
Max.: 120 cm
(47.24 in)Min.: 8 cm
(3.15 in)- Thickness
Max.: 6 mm
(0.236 in)Min.: 0.08 mm
(0.003 in)
Description
Overview
Rulon® W2 is a black PTFE-based carbon-filled polymer developed for fresh-water applications. It exhibits low friction and excellent wear characteristics (one of the lowest wear rates in fresh water) and provides good thermal dissipation to help prevent shaft distress. Its tribological properties are enhanced when wet and the material does not absorb water. It is compatible with most metal substrates and with many soft mating surfaces. Rulon® W2 is offered as a molded and precision-machined PTFE or filled PTFE composite formulation designed to control wear and friction for specific applications and environments. It is a suitable alternative to Rulon® J when superior chemical resistance is required, but it should not be used on very soft mating surfaces or where electrical insulation is needed.
Key features / benefits
Applications
Performance highlights (from product charts)
Manufacturing & form factors
Material is supplied via compression molding and precision machining. Typical supplied forms include rods, tubes, sheets and tapes.
Standard specifications (summary)
Materials: Black fluoropolymer · Engineered carbon filled
Service Conditions: Temperature: -240°C to +288°C · Mechanical Strength: 7 MPa
Manufacturing Process: Compression molding
Features: Friction coefficient: 0.15 - 0.30 · Max PV (dry/lub): 0.35 MPa·m/s
Dimensions: Rods and Tubes: (ϕ) 1.2 m x (L) 3 m · Sheets: (L,W) 610 mm x (ϕ) 80 mm · Tapes: (W) 1 m x (T) = [0.08;6] mm
Notes / limitations
Not recommended for use on very soft mating surfaces or where electrical insulation is required.
Rulon® W2 is a black PTFE-based carbon-filled polymer developed for fresh-water applications. It exhibits low friction and excellent wear characteristics (one of the lowest wear rates in fresh water) and provides good thermal dissipation to help prevent shaft distress. Its tribological properties are enhanced when wet and the material does not absorb water. It is compatible with most metal substrates and with many soft mating surfaces. Rulon® W2 is offered as a molded and precision-machined PTFE or filled PTFE composite formulation designed to control wear and friction for specific applications and environments. It is a suitable alternative to Rulon® J when superior chemical resistance is required, but it should not be used on very soft mating surfaces or where electrical insulation is needed.
Key features / benefits
- Low coefficient of friction (typical range 0.15 – 0.30)
- Excellent wear resistance in fresh water (one of the lowest wear rates in fresh water)
- Good thermal dissipation to prevent shaft distress
- Properties improve when wet; minimal moisture absorption
- Dimensional stability in chemical environments
- Max PV (dry/lub): 0.35 MPa·m/s
Applications
- Pumps (including fresh-water submerged pumps)
- Mixers and compressors
- Appliances
- Thrust bearings and wear bands
- Plating tanks and hydraulic presses
- Linear slides, pipe supports, insulators
Performance highlights (from product charts)
- Superior dry friction
- Stick/slip elimination
- Hardware abrasion reduction
- Minimal moisture absorption
- Dimensional stability in a wide range of chemicals
Manufacturing & form factors
Material is supplied via compression molding and precision machining. Typical supplied forms include rods, tubes, sheets and tapes.
Standard specifications (summary)
Materials: Black fluoropolymer · Engineered carbon filled
Service Conditions: Temperature: -240°C to +288°C · Mechanical Strength: 7 MPa
Manufacturing Process: Compression molding
Features: Friction coefficient: 0.15 - 0.30 · Max PV (dry/lub): 0.35 MPa·m/s
Dimensions: Rods and Tubes: (ϕ) 1.2 m x (L) 3 m · Sheets: (L,W) 610 mm x (ϕ) 80 mm · Tapes: (W) 1 m x (T) = [0.08;6] mm
Notes / limitations
Not recommended for use on very soft mating surfaces or where electrical insulation is required.
