Ball bearing PTFE Rulon® 1337

rodsheetroll

Product Overview Rulon® 1337 is a tan PTFE-based material composed entirely of FDA- and USDA-compliant components. It provides excellent physical properties and broad chemical compatibility (except concentrated sulfuric acid), making it suitable for wash-down environments in food and pharmaceutical processing. It has a slightly lower coefficient of friction than Rulon® J, resulting in extended service life and reduced abrasion against softer mating surfaces. Compatible with most commercially available natural lubricants for additional friction reduction.

Key Benefits

• FDA and USDA compliant formulation for food and pharmaceutical wash-down environments
• Lower coefficient of friction vs Rulon® J for extended life and reduced abrasion on softer surfaces
• Compatible with most commercially available natural lubricants to further lower friction
• Chemically compatible with the majority of chemicals (except concentrated sulfuric acid)
• Good dimensional stability and minimal moisture absorption; suitable for wet, dry and vacuum conditions

Applications

• Pumps
• Mixers
• Compressors
• Appliances
• Chute liners
• Insulators
• Linear slides
• Shaft bearings
• Seals
• Wear bands

Standard Specifications (table) Materials : Dull turquoise fluoropolymer
Engineered organic-filled
Service Conditions : Temperature : -240°C to +288°C
Mechanical Strength : 6.9 MPa
Manufacturing Process : Compression molding
Features : Friction coefficient: 0.10 - 0.20
Max PV (dry/lub): 0.35 MPa.m/s
Dimension : Rods and Tubes: (ϕ) 1.2m x (L) 3m
Sheets: (L,W) 610 mm x (ϕ) 80mm
Tapes: (W) 1m x (T) = [0.08;6] mm

Performance Highlights

• Superior dry friction performance
• Elimination of stick/slip
• Reduction of hardware abrasion
• Minimal moisture absorption
• Dimensional stability across a wide range of chemicals

Typical Product Forms

• Automatically molded bearings and components
• Sleeve, flanged and thrust bearings
• Stamped and formed seals
• Extruded shapes
• Machined parts and molded shapes

Technical specifications

• Brand : Rulon®
• Formulation : FDA and USDA compliant, engineered organic-filled PTFE fluoropolymer
• Service Temperature : -240°C to +288°C
• Mechanical Strength : 6.9 MPa
• Coefficient of friction : 0.10 - 0.20
• Max PV (dry/lubricated) : 0.35 MPa·m/s
• Manufacturing Process : Compression molding
• Chemical Compatibility : Compatible with most chemicals except concentrated sulfuric acid
• Available forms : rods, tubes, sheets, tapes; multiple standard dimensions listed above
• Typical applications : pumps, mixers, compressors, bearings, seals, wear components
