PTFE rod Rulon® J

sheetribbonroll

Overview
Rulon® J is a gold-colored, reinforced all-polymeric PTFE compound engineered for low friction and controlled wear against soft mating surfaces such as 316 stainless steel, aluminum, mild steel, brass and many plastics. The material is shaft-friendly, self-lubricating and suitable for bearing and wear-component applications where stick-slip and abrasion must be minimized.

Performance & Typical Uses
Rulon® J delivers one of the lowest coefficients of friction among commercially available blended PTFE compounds, making it ideal for high-speed, low-load applications. Typical uses include industrial wear pads, production compressors, start/stop mechanisms, linear guides and other components requiring consistent low friction and reduced abrasion.

Manufacturing & Formulation
The compound is produced by compression molding and precision machining from PTFE and polymer-filled PTFE composites. The engineered formulation controls tribological properties to match application-specific requirements and environments.

Key Benefits

• Low coefficient of friction (0.12–0.20)
• Shaft-friendly against soft mating surfaces
• Self-lubricating — reduces maintenance needs
• Suitable for bearings and wear components in high-speed, low-load conditions

Standard Specifications
Materials: gold fluoropolymer; engineered polymer-filled PTFE
Service conditions: Temperature range: -269°C to +315°C; Mechanical strength: 5.5 MPa
Manufacturing process: Compression molding
Features: Friction coefficient: 0.12 - 0.20; Max PV (dry/lub): 0.26 MPa·m/s
Dimensions: Rods and Tubes: (ϕ) 1.2m x (L) 3m; Sheets: (L,W) 610 mm x (ϕ) 80mm; Tapes: (W) 1m x (T) = [0.08;6] mm

Performance Highlights (Precision Fit)

• Very good Max PV performance for intended uses
• Excellent compatibility with soft mating surfaces
• Low coefficient of friction and reduced wear
• Creep resistance and dimensional stability
• Wide operating temperature range and chemical inertness

Lifetime Confidence

• Superior dry friction performance
• Stick/slip elimination in dynamic applications
• Reduced hardware abrasion and longer component life
• Minimal moisture absorption
• Dimensional stability in common chemical environments

Typical Product Forms & Applications

• Molded bearings and precision components
• Skived sheets and machined parts
• Sleeves, flanged and thrust bearings
• Stamped and formed seals; extruded profiles
• Tapes and sealing laminates

Common applications include printers, copiers, air compressors, appliances, insulators, linear slides, anemometers, wear bands, solenoid valves and refrigeration valves.

Caractéristiques / spécifications techniques

• Materials: Gold fluoropolymer; engineered polymer-filled PTFE
• Temperature range: -269°C to +315°C
• Mechanical strength: 5.5 MPa
• Manufacturing: Compression molding
• Friction coefficient: 0.12 - 0.20
• Max PV (dry/lub): 0.26 MPa·m/s
• Available dimensions: Rods/Tubes, Sheets, Tapes (see table above)
