PA6 cable gland ExO series
PApolyamidefor hazardous areas

PA6 cable gland - ExO series - ORTAC - PA / polyamide / for hazardous areas
PA6 cable gland - ExO series - ORTAC - PA / polyamide / for hazardous areas
PA6 cable gland - ExO series - ORTAC - PA / polyamide / for hazardous areas - image - 2
Add to favorites
Compare this product
Go to the ORTAC website for more information

Characteristics

Material
PA6, PA, polyamide
Protection level
for hazardous areas, IP68, explosion-proof
Other characteristics
PG thread, threaded
Cable diameter

Max.: 44 mm
(1.73 in)

Min.: 3 mm
(0.12 in)

Clamping range

Max.: 44 mm
(1.7 in)

Min.: 3 mm
(0.1 in)

Operating temperature

Max.: 100 °C
(212 °F)

Min.: -30 °C
(-22 °F)

Description

Product
Ex-i Blue EX is a polyamide (PA6) Ex-proof cable gland available in PG thread and long-thread variants, colour Blue (RAL 5012).

Key features
  • Series: ExO (polyamide Ex-proof gland)
  • Connection thread: PG (DIN 40430)
  • Ingress protection: IP68 (5 Bar)
  • Operating temperature: -30 °C to +100 °C
  • Material: Polyamide PA6
  • Colour: Blue (RAL 5012)


Available sizes and codes — PG
  • PG-7 — ExOXXORM 01 — H 24 — GL 8 — Wrench 15 — Clamping/Range 3 - 6,5
  • PG-9 — ExOXXORM 02 — H 28 — GL 8 — Wrench 19 — Clamping/Range 4 - 8
  • PG-11 — ExOXXORM 03 — H 29 — GL 8 — Wrench 22 — Clamping/Range 5 - 10
  • PG-13.5 — ExOXXORM 04RS — H 29 — GL 9 — Wrench 24 — Clamping/Range 4 - 10
  • PG-13.5 — ExOXXORM 04 — H 29 — GL 9 — Wrench 24 — Clamping/Range 6 - 12
  • PG-16 — ExOXXORM 05 — H 33 — GL 9 — Wrench 27 — Clamping/Range 10 - 14
  • PG-21 — ExOXXORM 06 — H 38 — GL 11 — Wrench 33 — Clamping/Range 13 - 18
  • PG-21 — ExOXXORBM 06/9-17 — H 38 — GL 11 — Wrench 33 — Clamping/Range 9 - 17
  • PG-29 — ExOXXORM 07 — H 41 — GL 11 — Wrench 42 — Clamping/Range 18 - 25
  • PG-36 — ExOXXORM 08 — H 51 — GL 11 — Wrench 53 — Clamping/Range 22 - 32
  • PG-42 — ExOXXORM 09 — H 53 — GL 11 — Wrench 60 — Clamping/Range 30 - 38
  • PG-48 — ExOXXORM 10 — H 55 — GL 14 — Wrench 65 — Clamping/Range 34 - 44


Available sizes and codes — Long Thread
  • PG-7 — ExOXXORML 01 — H 24 — GL 15 — Wrench 15 — Range 3 - 6,5
  • PG-9 — ExOXXORML 02 — H 28 — GL 15 — Wrench 19 — Range 4 - 8
  • PG-11 — ExOXXORML 03A — H 29 — GL 10 — Wrench 22 — Range 5 - 10
  • PG-11 — ExOXXORML 03 — H 29 — GL 15 — Wrench 22 — Range 5 - 10
  • PG-13.5 — ExOXXORML 04RS — H 29 — GL 15 — Wrench 24 — Range 4 - 10
  • PG-13.5 — ExOXXORML 04 — H 29 — GL 15 — Wrench 24 — Range 6 - 12
  • PG-16 — ExOXXORML 05 — H 33 — GL 15 — Wrench 27 — Range 10 - 14
  • PG-21 — ExOXXORML 06 — H 38 — GL 15 — Wrench 33 — Range 13 - 18
  • PG-21 — ExOXXORML 06/9-17 — H 38 — GL 15 — Wrench 33 — Range 9 - 17


Technical specifications
  • Protection code: II 2G Ex eb IIC Gb II 2D Ex tb IIIC Db
  • Certificates: IEP 20 ATEX 0750 X; ROHS; CE; PT; TUV
  • Standards: EN 60079-0, EN 60079-7, EN 60079-31
  • Gland body material: Polyamide PA6
  • Connection thread: PG (DIN 40430)
  • Ingress protection: IP68 (5 Bar)
  • Operating temperature: -30 °C to +100 °C
  • Colour: Blue (RAL 5012)


Applications
  • Zones: ZONE1, ZONE2, ZONE21, ZONE22
  • Gas groups: IIA, IIB, IIC
  • Use cases: cable entry for electrical installations in hazardous areas requiring Ex protection
