Water pump GY-028 serieswith electric motorself-primingside-channel
Add to favorites
Compare this product
Characteristics
- Fluid
- water
- Operation
- with electric motor
- Priming
- self-priming
- Technology
- side-channel
- Mobility
- stationary
- Domain
- industrial
- Applications
- recovery, boiler
- Other characteristics
- compact, suction, mechanical
- Flow
Min.: 0 m³/h
(0 ft³/h)Max.: 45 m³/h
(1,589.16 ft³/h)- Head
Max.: 240 m
(787'04" )Min.: 0 m
(0'00" )- Power
0.55 kW, 1.1 kW, 1.5 kW
(0.75 hp, 1.5 hp, 2.04 hp)- Fluid temperature
Max.: 120 °C
(248 °F)Min.: 0 °C
(32 °F)- Length
395 mm, 467 mm
(16 in, 18 in)- Width
138 mm, 170 mm
(5.43 in, 6.69 in)- Height
190 mm, 238 mm
(7.48 in, 9.37 in)- Weight
4 kg, 5.4 kg, 8.1 kg
(8.82 lb, 11.9 lb, 17.86 lb)
Description
Closed coupled version
With elastic coupling
Suitable for the delivery of gas shares
Self priming
Material design
Stainless steel
Cast iron
Suction connection
G 3/4
Pressure connection
G 3/4
Sealing
Mechanical seal
Applications
Power engineering
Delivery of hot water in boiler sytems
Recovery of condensates (water)
Advantages
Suitable for the delivery of gas shares
Steep characteristic curve
High pressures with compact design
