Signal isolator SUP-602S
currentvoltage

signal isolator
signal isolator
signal isolator
signal isolator
signal isolator
Add to favorites
Compare this product


Characteristics

Type
signal
Electrical characteristics
current, voltage

Description

SUP-602S Signal isolator utilized in automated control systems is a kind of instrument for transformation & distribution, isolation, transmission, operation of a variety of industrial signal, it can also be used with all kinds of industrial sensor to retrieve parameters of signals, isolation, transformation and transmission for remote monitoring local data collection. Features • Allowed input signal: DC: 0(4)mA~20mA;0mA~10mA Other signal types may be customized as required, see the product label for details; • Input impedance: about 100Ω • Allowed output signal: • Current: 0(4)mA~20mA;0mA~10mA Voltage: 0(1) V~5V;0V~10V Other signal types may be customized as required, see the product label for the specific signal types; • Output load capacity: 0(4)mA~20mA:≤550Ω;0mA~10mA:≤1.1kΩ 0(1)V~5V:≥1MΩ; 0V~10V:≥2MΩ Other load demands may be customized as required, see the product label for details. • Distribution output voltage: No-load voltage≤26V, full-load voltage≥23V Accuracy of isolated transmission: ±0.1%F∙S(25℃±2℃) • Temperature drift: 40ppm/℃ • Response time: ≤0.5s Specification • Allowed input signal: DC: 0(4)mA~20mA;0mA~10mA Other signal types may be customized as required, see the product label for details; • Input impedance: about 100Ω • Allowed output signal: • Current: 0(4)mA~20mA;0mA~10mA Voltage: 0(1) V~5V;0V~10V Other signal types may be customized as required, see the product label for the specific signal types; • Output load capacity: 0(4)mA~20mA:≤550Ω;0mA~10mA:≤1.1kΩ 0(1)V~5V:≥1MΩ; 0V~10V:≥2MΩ
