Abrasion tester 393
Add to favorites
Compare this product
Description
This is an abrasion tester in which a plastic specimen set on a rotating shaft is brought into contact with another material under a constant load.
JIS K 7218 - Testing Methods for Sliding Wear Resistance of Plastics
Needle diameter - ∅0.45mm
Needle travel distance - 20mm
Speed - 55cpm (Adjustable in 50 to 60cpm at the time of inspection)
Abrasion length - 15.5±1mm
Vertical force - 7N
Specimen base - Groove depth 0.4mm and 0.8mm (2 kinds)
Counter - Electronic counter, 6 digits
Power supply - Single-phase, AC100V, 50/60Hz, 0.3kVA (or specify)
Dimensions - W110 × D410 × H290mm
Weight - Approx. 25kg
Catalogs
No catalogs are available for this product.
See all of Toyoseiki‘s catalogsOther Toyoseiki products
Abrasion / Coefficient of Friction (COF)
