Standard response sprinkler TY-L

uprighthangingside mounted

Overview
Series TY-L standard-response solder-type sprinklers are engineered for commercial occupancies such as banks, hotels, shopping centers and office buildings. These sprinklers provide standard coverage options and are suitable for light, ordinary and extra-hazard occupancies where a solder-type operating element is specified.

General Information
Orientation: Upright, Pendent, Recessed Pendent, Horizontal Sidewall
K-Factor: Up to 8.0
Temperature Rating: Up to 280°F (≈138°C)
Response: Standard

Features

• UL and C-UL Listed; FM and LPCB Approved
• Available in upright, pendent, recessed pendent and horizontal sidewall variants
• Refer to TFP110 and TFP120 technical publications for model-specific listing and installation details

Benefits

• Versatile — Multiple orientations and finishes to match installation requirements
• Applicable — Designed for common commercial hazard classifications
• Proven pedigree — Tyco® product lineage with extensive field experience

Technical specifications

• Occupancy Type: Light Hazard, Ordinary Hazard, Extra Hazard
• K-Factor: Up to 8.0
• Listings and Approvals: UL and C-UL Listed; FM and LPCB Approved
• Note: See Technical Data Sheet for detailed hydraulic and installation data
• SIN Numbers: TY3311, TY3111, TY3211, TY4111, TY4211, TY4811, TY4911
• Thread: Up to 3/4-inch
• Wrench Recessed: W-Type 10
• Wrench: W-Type 9
