Water pressure regulator and reducer PRV-1A

diaphragmfor water systemsflange

Overview
The PRV-1A is a pilot-operated pressure reducing valve designed for pressure control on sprinkler systems, hose connections and water-filled pipe networks. It reduces a higher inlet pressure to a controlled lower delivery pressure and maintains the outlet set pressure (static and residual) within a narrow range despite fluctuations in supply pressure or flow. The valve uses the DV-5A diaphragm body and is available in flange-by-flange and grooved-by-grooved end connections. The factory outlet set pressure is approximately 125 psi.

Key information (table)
Listings and Approvals: UL and C-UL Listed, FM Approved
Sizes: 2 inch to 8 inch (DN50 to DN200)

Features

• Simple trim configuration for straightforward maintenance
• In-line serviceable design
• UL and C-UL Listed, FM Approved
• Factory-assembled and fully trimmed
• Single pilot valve adaptable to any outlet set pressure via a dedicated subassembly

Benefits

• Simple design — single moving part minimizes wear and eases maintenance.
• Install ready — delivered factory-assembled and pre-trimmed for faster installation.
• Proven track record — Tyco® products have been used to protect facilities for over a century.

caractéristiques / spécifications techniques

• Listings and Approvals: UL and C-UL Listed, FM Approved
• Pressure Rating: 300 psi (20.7 bar)
• Sizes: 2 inch to 8 inch (DN50 to DN200)
• Valve Type: Pressure reducing valve (pilot-operated)
• Factory outlet set pressure: approximately 125 psi
• Valve body: DV-5A diaphragm design; available flange-by-flange and grooved-by-grooved
