DN: 20 mm - 1,000 mm
Pressure: 16 bar
Temperature: -40 °C - 200 °C
... Thanks to their design and material diversity, centrally mounted, resilient seated shut-off and control valves are almost universally usable. Whether the medium is water, powder or gas - with a broad range of materials, we can offer you ...
EBRO ARMATUREN Gebr. Bröer GmbH
DN: 50 mm - 600 mm
Pressure: 16 bar
Temperature: -10 °C - 120 °C
... Thanks to their design and material diversity, centrally mounted, resilient seated shut-off and control valves are almost universally usable. Whether the medium is water, powder or gas - with a broad range of materials, we can offer you ...
EBRO ARMATUREN Gebr. Bröer GmbH
DN: 50 mm - 300 mm
Pressure: 19.2 bar
Temperature: -10 °C - 120 °C
... FEATURES AND BENEFITS - Vulcanised liner for severe service conditions and Vacuum applications - Fully lugged body for end of line services - Triple shaft bearings prevent shaft defl ection - Accurate machining of components results in low torques ...
EBRO ARMATUREN Gebr. Bröer GmbH
DN: 50 mm - 900 mm
Pressure: 10 bar - 40 bar
... high-performance, all-purpose valve is designed for precise throttling control or on-off service with lighter weight piping systems and less expensive, energy-efficient actuators. Broad application versatility via numerous design options: ...
FLOWSERVE
DN: 300, 250 mm
Pressure: 10 bar
Temperature: -10 °C - 70 °C
... V5422 Series butterfly valves are used primarily to provide isolation service in central plant applications, such as boilers, chillers, cooling towers, and other heat exchangers. The V5 Series Actuated Butterfly Valves ...
DN: 50 mm - 300 mm
Pressure: 12 bar - 20.7 bar
... Sizes: 2 inch to 12 inch (DN50 to DN300)
Valve Type: Butterfly
Valve
Technical specifications
- Brand: Tyco Fire
- Model: BFV-300
- Connection types: Grooved (standard); wafer-style
DN: 100 mm
Pressure: 16 bar
Temperature: -10 °C - 80 °C
... Butterfly valve is used as motorized or shut-off valves in heating, ventilation and air conditioning systems applications. In open and closed circuits For 2-position (SPDT) or DC 0…10 V control signals ...
DN: 50 mm - 300 mm
Pressure: 10 bar
Flow rate: 740 l/min - 50,000 l/min
... Type 578 butterfly valves with high corrosion resistance are perfect for use in chemical processing and industrial water treatment. Their versatile design minimizes torque and allows them to be used as a wafer-style or ...
GF Piping Systems
DN: 80 mm - 100 mm
Pressure: 16 bar
... description
Butterfly
valve with EPDM O-ring, made from UPVC (U-PVC), available in DN80 and DN100 sizes (PN16).
Product details
- Brand: U-PVC Check Valves
- Category: Check Valves
- Type:
DN: 25 mm - 600 mm
Pressure: 0 bar - 16 bar
Temperature: -10 °C - 160 °C
... Soft-sealing, centrally mounted butterfly
valve
The GEMÜ R487 Victoria soft seated metal butterfly
valve is manually operated. It has a hand lever or gearbox depending on customer requirements. The butterfly
valve ...
GEMÜ Gebrüder Müller Apparatebau GmbH & Co. KG
DN: 25 mm - 1,200 mm
Pressure: 0 bar - 10 bar
Temperature: -20 °C - 200 °C
... PTFE-sealing, centrally mounted butterfly
valve
The GEMÜ 498 Edessa PTFE-sealing, centric butterfly
valve is actuated by an electric motor. Various metal or plastic on/off or control actuators are available. Disc ...
GEMÜ Gebrüder Müller Apparatebau GmbH & Co. KG
DN: 50 mm - 300 mm
Pressure: 0 bar - 10 bar
Temperature: 5 °C - 80 °C
... butterfly
valve
The GEMÜ D451 soft seated butterfly
valve has a metal actuator and is pneumatically operated. The "Normally Closed", "Normally Open" and "Double Acting" control functions ...
GEMÜ Gebrüder Müller Apparatebau GmbH & Co. KG
DN: 15 mm - 250 mm
Pressure: 10 bar - 100 bar
Temperature: -60 °C - 350 °C
... The sliding gate control valve type 8021 in reinforced GS3 design with integrated positioner is suitable for a wide range of process applications. Media such as steam, liquids, gases, etc. can perfectly be handled. Size: DN ...
Schubert & Salzer Control Systems GmbH
DN: 15 mm - 250 mm
Pressure: 10 bar - 40 bar
Temperature: -60 °C - 350 °C
... The sliding gate control valve type 8043 in a reinforced version and long design with piston actuator and integrated positioner is due to its compact design universally applicable for neutral and aggressive media in the chemical industry, ...
Schubert & Salzer Control Systems GmbH
DN: 15 mm - 125 mm
Pressure: 10 bar - 40 bar
Temperature: -60 °C - 230 °C
... This compact motor valve is used in a wide range of process engineering control tasks. It is particularly characterised by its very short design. Most media such as steam, fluids, gases, etc. can be excellently controlled with it. This ...
Schubert & Salzer Control Systems GmbH
DN: 125, 150 mm
Pressure: 10 bar
... The FE is a butterfly valve for shutting off or regulating flow, specifically designed for water conveyance applications. In addition to the manually actuated version, FE is also available in FE/ CE electrically actuated and FE/CP pneumatically ...
FIP - Formatura Iniezione Polimeri
DN: 200 mm
Pressure: 10 bar
... The FE is a butterfly valve for shutting off or regulating flow, specifically designed for water conveyance applications. In addition to the manually actuated version, FE is also available in FE/ CE electrically actuated and FE/CP pneumatically ...
FIP - Formatura Iniezione Polimeri
DN: 40, 100, 50, 65, 80 mm
Pressure: 16, 10 bar
Temperature: 0 °C - 60 °C
... Butterfly valve with multi-volt electric actuator 90-240 V AC 50-60 Hz. The FE is a butterfly valve for shutting off or regulating flow, specifically designed for water conveyance applications. In addition to the manually ...
FIP - Formatura Iniezione Polimeri
DN: 32, 40 mm
Pressure: 16 bar
Temperature: 5 °C - 85 °C
... time: 45 sec for 90° rotation – 22Nm Protected type, manual emergency override, 2 extra micro switches BUTTERFLY Wafer valve PN16 Body and disc in GG25, polyamide covering, seal seat: Nitrile or EPDM ...
DN: 65, 50, 100, 80 mm
Pressure: 16 bar
Temperature: -10 °C - 120 °C
... time: 45 sec for 90° rotation – 22Nm Protected type, manual emergency override, 2 extra micro switches BUTTERFLY Wafer valve PN16 Body and disc in GG25, polyamide covering, seal seat: Nitrile or EPDM ...
DN: 100, 125, 250, 150, 200 mm
Pressure: 16 bar
Temperature: -20 °C - 55 °C
... time: 45 sec for 90° rotation – 22Nm Protected type, manual emergency override, 2 extra micro switches BUTTERFLY Wafer valve PN16 Body and disc in GG25, polyamide covering, seal seat: Nitrile or EPDM ...
DN: 2.5 in - 12 in
Pressure: 300 psi
Temperature: 0 °C - 80 °C
... different industries. How do you install a wafer type butterfly valve? 1．Set auxiliary screw at proper place, to regulate distance between two flanges or groove faces. 2．For wafer butterfly valve, ...
DN: 40 mm - 300 mm
Pressure: 6, 10, 16 bar
Temperature: -30 °C - 200 °C
... Bi-directional zéro leakage butterfly valve. Accurate dual stem sealing prevents leakage. Design Standard : ISO 5211, API 609, ASME B16.5 150#. ISO Pad for mounting, Gear Operator / Actuator. The butterfly valve can ...
UFLOW AUTOMATION
DN: 40 mm - 300 mm
Pressure: 10, 6, 16 bar
Temperature: -30 °C - 200 °C
... Bi-directional zéro leakage butterfly valve. Accurate dual stem sealing prevents leakage. Design Standard: ISO 5211, API 609, ASME B16.5 150#^ ISO Pad for mounting, Gear Operator / Actuator The butterfly valve can ...
UFLOW AUTOMATION
DN: 40 mm - 250 mm
Pressure: 10, 6 bar
Temperature: -30 °C - 200 °C
... leakage. Design Standard: ISO 5211, API 609, ASME B16.5 150#^ ISO Pad for mounting, Gear Operator / Actuator The butterfly valve can be mounted between flanges as per ASME. Face-to-Face Dimension: API 609 (CAT A). Leakage Class: ...
UFLOW AUTOMATION
DN: 15 mm - 150 mm
Pressure: 40, 16 bar
Temperature: -29 °C - 175 °C
... WAFER ATEX BALL VALVE WITH ISO MOUNTING PAD - FULL BORE - LOCKABLE HANDLE - STAINLESS STEEL 316 ...
DN: 40 mm - 150 mm
Pressure: 10, 16, 6 bar
Temperature: -30 °C - 110 °C
... BUTTERFLY VALVE WITH LOCATING HOLES - GJS500-7 CAST IRON BODY - CF8M STAINLESS STEEL BUTTERFLY - EPDM GASKET ...
... The T-KV W121 series wafer type butterfly valve is enhanced to accommodate a range of applications such as treatment for water and air, heating, ventilation, and air conditioning operations, sewage management, and textile ...
Pressure: 10 bar
Temperature: -30 °C - 130 °C
... Tork's T-KV .W1120 is an industrial application valve which is recommended for applications that include ship building, hot and cold water, HVAC application, textile units, base and salty conditions, acids-alcali and gas and exhaust units. ...
DN: 50 mm - 1,200 mm
Pressure: 10, 6, 5, 4, 2 bar
... The Knife Gate Valve is a uni-directional wafer valve for general industrial application.It is predominantly used in the paper and pulp chemical industries mining industries power station ...
DN: 50 mm - 600 mm
Pressure: 10, 4, 6, 5 bar
... features of Knife Gate Valve type B The structure of the bi-directional Knife Gate Valves encompasses a two-part wafer style body screwed together, with reinforced ribs for larger nominal diameters for ...
DN: 15 mm - 150 mm
Pressure: 10 bar - 40 bar
... Product overview
A compact
wafer-type full-bore ball
valve rated to ANSI Class 150 and PN10/16/40. Lightweight and space-saving, constructed in CF8M stainless steel. Available in multiple designs (Standard, ...
DN: 12.7 mm - 152.4 mm
Pressure: 10 bar - 40 bar
... | 1.4408 / 1.0619 | PTFE/RTFE (standard) or other options |
Wafer type, full port, ISO 15848-1 certified
Technical specifications
- Type: Wafer-type flanged ball valve, full bore
DN: 0 mm - 10,000 mm
Pressure: -10 bar - 7,000 bar
Temperature: -20 °C - 200 °C
... installation are required.
Category
- Flanged Ball Valve
- Wafer-Type Flanged Ball Valve
Technical specifications
- Brand: MARS Valve
DN: 32 mm - 1,400 mm
Pressure: 0 bar - 10 bar
Temperature: -20 °C - 180 °C
... knife gate valves experts, Flowrates will provide the finest solutions to your process. Our extensive range of knife gate valves enables our customers to solve problems on site trough our solutions. They are available ...
Flowrates
DN: 50 mm - 1,200 mm
Pressure: 6 bar - 16 bar
Temperature: -60 °C - 200 °C
... Butterfly Valves Reduced friction and increased service life thanks to spherical design elements Rounded and polished sealing surfaces of the disc reduce the torque and allow the use of smaller and cheaper actuators The ...
Flowrates
DN: 80 mm - 1,200 mm
Pressure: 10, 16, 25, 40 bar
Temperature: -50 °C - 220 °C
... BVD01 are characterized by unparalleled performance and quality in the range of high performance double offset butterfly valves. Optimized lip-type seat can automatically compensate for temperature and pressure variations. It has a ...
Flowrates
DN: 50 mm - 600 mm
Pressure: 4 bar - 10 bar
Temperature: -20 °C - 120 °C
... • Pneumatic Actuator -OF -NC -NA • Electric Actuator -220V -24V • Special voltages • Includes end of career ...
DIVATEC,SL
DN: 50 mm - 600 mm
Pressure: 4 bar - 10 bar
Temperature: 0 °C - 80 °C
... equipment Use • For sawing of piping systems Fluids • Neutral media and aggressive liquid or gaseous media if the valve components that contact the media are resistant to the service temperature according to the Divatec resistance ...
DIVATEC,SL
DN: 50 mm - 600 mm
Pressure: 6 bar
Flow rate: 44 m³/h - 15,900 m³/h
... ANSI/ASME B 16.5 Class 150, BS 1560: 1989, BS 4504, JIS B 2220 More butterfly valves We have other butterfly valves in our catalog. Contact us to find out all the valves we can offer you. ...
DIVATEC,SL
DN: 15 mm - 100 mm
Pressure: 16 bar - 40 bar
Temperature: -40 °C - 200 °C
... excursions to which the valve is subjected Greater precision in the alignment of axes due to a unique positioning in the process machining from raw material to finished valve Longer lifetime of the valve Less ...
OMAL Spa
DN: 50 mm - 300 mm
Pressure: 16 bar
Temperature: -30 °C - 200 °C
... Wafer type butterfly valve for installation between flanges EN 1092, PN 10/16, ASME class 150. Two-piece body, self-centring, one-piece disc and stem, bubble-tight up to 16 bar, vacuum-tight. Face-to-face dimension ...
GEFA Processtechnik
DN: 25 mm - 200 mm
Pressure: 10 bar - 40 bar
Temperature: -40 °C - 450 °C
... Neles® series E ball control valves are designed to meet the most severe erosive service requirements of wide range of industrial applications in pulp & paper, petro-chemical, refining and related industries. E series valves ...
Metso Automation
DN: 2 in - 12 in
Pressure: 200 psi
Temperature: 225, 250 °F
... international wafer type butterfly valve provides in-line bubble-tight shutoff at 200 PSI, recommended for quick installation and removal from piping. The valve performs well in commercial applications ...
DN: 3 in - 56 in
Pressure: 300 psi
Temperature: -50 °C - 650 °C
... Design to ASME B16.34/API609 Dimensions to ASME B16.5/B16.1/EN1092 Pressure Test to API598/ISO5208 ...
Taloar
DN: 2 in - 12 in
Pressure: 13.8 bar
... 2 to 12 in. (50 to 300mm) Description: Series BF-04 Wafer Style Butterfly Valves are used in HVAC, irrigation, OEM, commercial, and institutional applications and wherever positive shutoff is required to control the ...
DN: 40 mm - 500 mm
Pressure: 16, 10 bar
Temperature: -10 °C - 95 °C
... Butterfly valves, Butterfly valves semilug type, Butterfly valves semilug type on nodular cast iron PN 16 (EN-GJS-400-15) This butterfly valve is easily assembled at the end of a pipe, ...
Mival
DN: 80 mm - 400 mm
Pressure: 10 bar - 25 bar
Temperature: 0 °C - 350 °C
... tightness makes this valve an excellent choice for marine applications. CARGO VALVES FOR LIQUIDS The butterfly valve is useful for handling liquids. The metallic seat is not affected by a high velocity ...
DN: 50 mm - 300 mm
Pressure: 0 bar - 10 bar
Flow rate: 90 m³/h - 3,498 m³/h
... between the Flanges of ANSI B16.5, Cl.150. Characteristic: On-Off. For Air, Water, Oil, Gas, some Chemicals, Low pressure steam. Valve can be used on Combustion Equipments, Power Stations, Chemicals, Petro-chemicals, Pharmaceuticals and ...
DN: 50 mm - 600 mm
Pressure: 10 bar
... Resilient-seated knife-gate valve in fully flanged design, sealing in both flow directions, with integrated scraper system and free flow passage. Operation via electric actuator. Suitable for use as shut-off valve in ...
VAG-Group
DN: 50 mm - 1,200 mm
Temperature: -48 °C - 400 °C
... Hi-Seal, high performance butterfly valves offer efficient, bi-directional sealing across a wide spectrum of service conditions Design options • Soft seated • Fire safe • Metal seated ...
Pentair Valves & Controls
DN: 50 mm - 600 mm
Pressure: 4 bar - 10 bar
... 4 - 10 Body: EN-JL1040 Coating: Epoxy Reliable and versatile, resilient-seated knife gate valves. Can be used as butterfly valve as wafer type or end valve. For water, sewage. Industries: ...
DN: 80 mm - 300 mm
Pressure: 0 bar - 100 bar
... predefined levels. The valves have a wafer type design with an off-center butterfly disk so it can be mounted eccentrically. These valves will shut-off automatically when gas flows. This can only be reset ...
DN: 80 mm
Pressure: 10 bar
Temperature: -40 °C - 180 °C
... Features •Maximum mounting flexibility •Superior corrosion resistance •Extended lifetime •Minimized operating costs Specifications •Design - ISO/DIN •Nominal Pressure = 10 bar •Disc Lining = PFA •Body Lining = PTFE •Housing Material ...
DN: 25 mm - 150 mm
Pressure: 0 bar - 10 bar
Temperature: 130 °C
... Function: leakage butterfly valve NC in closed position, flushing valves NO in open position With activation of air pressure, first the flushing valves close, then the leakage butterfly valve ...
DN: 40 mm - 300 mm
Pressure: 10, 16 bar
Temperature: -15 °C - 130 °C
... Body material Ductile iron GGG50 PN (end) PN10/16-ASA150-JIS10K Contact sealing Heat EPDM Disc material Ductile iron GGG50 coated Connection between flanges Operating system Lever ...
TECOFI
DN: 40 mm - 600 mm
Pressure: 16, 10 bar
Temperature: -20 °C - 110 °C
... The 1150 series is famous for the long neck used in isolation. It has an ISO 5211 mounting pad and is a wafer type valve. It has ISO PN10 flanges that range between DN450 to DN 1400. It has a removable seat as well as ...
SFERACO
DN: 0 mm - 10,000 mm
Pressure: 6 bar - 64 bar
... request).
AVAILABLE VERSIONS
- Standard wafer valve
- Wafer valve with gearbox/box
- Motorized wafer valve with gearbox/box
- Motorized
DN: 50 mm - 1,200 mm
Pressure: 2.5 bar - 100 bar
Temperature: -45 °C - 250 °C
... Di Nicola manufactures single eccentric butterfly valves type lug, wafer and flanged in ductil iron EN GJS 400 to EN GJS 500 , malleable cast iron GJL 250 and high- nickel NI resist , carbon steel ASTM 216 WCB / N + GP ...
DN: 0.5 in - 4 in
Pressure: 0 bar - 16 bar
Temperature: -20 °C - 180 °C
... TECHNICAL INFORMATION1. Full port ball valve, Wafer type2. Assembly with flanges DIN PN-163. Made of Stainless Steel AISI 3164. Ball seats PTFE + 15% G.F.5. Blow - out proof stem6. Direct mounting actuator according ISO ...
DN: 25 mm - 125 mm
... The GRC Series, manufactured by Gemels, is a 2-way high pressure carbon steel ball valve that is specially designed to produce a shutoff even after abandonment. This valve works within a temperature range of -20°C up ...
