Wall-mounted fume extractor RFHT F400 Series

industrial

Exhaust ventilation of warehouses, shop and industrial halls, farm buildings in agriculture, etc. Due to the high temperature resistance, they are recommended especially as extraction from over grates, from hoods in the meat industry and gastronomy. Roof fan with vertical air discharge. Designed for smoke extraction systems, as well as for comfort ventilation, it has the F120400 certificate in accordance with the EN 12101-3 standard. Construction The fan has a base made of galvanized sheet. Aluminum sheet housing. The outer casing and the engine compartment are insulated with a 30mm thick mat in the A1 flammability class (non-flammable). The rotor is made of steel, ensuring durability and adequate temperature resistance. The fan is equipped with a service switch as standard. Motor Electric motor made in accordance with the applicable Directives and efficiency classes, marked with the CE mark. Insulation class - F. Protection class - IP 55. Power supply - three-phase depending on the model 230 / 400V 50Hz, 400V 50Hz or 400 / 690V 50Hz. The motors are available in single and two-speed versions. The electric motors used allow for external speed control with a frequency converter.
