7" vehicle-mount computer FM07

Intel® Pentium® N4200intel® celeron® N3350MIL-STD-810G

Overview
Winmate FM07 is a 7-inch vehicle-mounted computer engineered for warehouse logistics, fleet management and forklift operations. It provides rugged, mission-capable performance with wide-range vehicle power support, M12 waterproof connectors, IP65 protection and MIL-STD-810G shock and vibration resistance. The FM07 includes a projected capacitive multi-touch display and ships with Intel® Celeron® N3350 (default) or Intel® Pentium N4200 (optional). Windows 10 IoT Enterprise (64-bit) is the default OS; Linux Ubuntu 20.04 is available as an option.

Key features

• Intel® Celeron® N3350 (Apollo Lake) processor (default); Intel® Pentium® N4200 optional
• 7.0" 1024 x 600 projected capacitive multi-touch display, high brightness (1000 nits)
• Wide vehicle power input 9–36 V DC with ignition control
• M12 waterproof connectors and M12 Gigabit LAN
• IP65 dustproof and waterproof enclosures
• Shock and vibration resistance compliant with MIL-STD-810G
• Wireless: WLAN, Bluetooth, GNSS (GPS/GLONASS); optional WWAN (4G/LTE)
• Front programmable function keys (5 keys)

Certifications

• MIL-STD-810G
• IP65
• E-Mark
• FCC
• CE

Product details — Highlights

• Display: 7.0-inch projected capacitive multi-touch, 1024 x 600, 1000 nits, 800:1 contrast, active area 152.2144 x 85.92 mm
• System: Intel Celeron N3350 1.1 GHz (up to 2.4 GHz) default; Intel Pentium N4200 optional; 4 GB default (8 GB optional); 1 x M.2 2242 SSD 128 GB
• Ethernet: 1 x Intel® Gigabit Ethernet controller (M12 type)
• Security: TPM 2.0
• OS: Windows 10 IoT Enterprise (64-bit) default; Linux Ubuntu 20.04 optional
• Vehicle power: internal wide-range converter (9–36 V DC) with ignition control; power consumption max 35 W
• I/O ports: 2 x USB (via DB9 on dock), 1 x RS232/422/485 (default RS232), 1 x Gigabit LAN (M12), 1 x speaker, 1 x SIM slot, DIDO (5 DI / 3 DO), 2 x CANBUS
• Mechanical: dimensions 190 x 146 x 40 mm; weight 1.25 kg; RAM mount and VESA 75 x 75 mm supported; fanless design
• Environment: operating humidity 10%–95% RH; operating temperature -20 °C to 60 °C; shock and vibration per MIL-STD-810G

Mounting solutions (tables)
Mounting 1 – No Drill Solution (table)
No. | Component | RAM Mount Part Number | Description | QTY
A | RAM Clamp Mounts - on the forklift | RAM-D-247U-4 | Clamp base with 2.25” Ball | 1
B | RAM Arm | RAM-D-201U | Arm for 2.25” Ball (L: 8.375”) | 1
C | RAM Ball on the device side | RAM-D-2461U | 75 x 75 mm VESA with 2.25” Ball | 1
C-1 | Screw | - | SUS304 M4 x 12 mm Screw | 4
C-2 | Washer | - | M4 Washer | 4

Mounting 2 – Drill Solution (table)
No. | Component | RAM Mount Part Number | Description | QTY
A1 | RAM round base mounts - on the forklift | RAM-D-202U | 3.68" Round Base with 2.25" Ball | 1
A1-1 | Screw | - | SUS304 M8 x 40 mm Screw | 4
B | RAM Arm | RAM-D-201U | Arm for 2.25” Ball (L: 8.375”) | 1
C | RAM Ball on the device side | RAM-D-2461U | 75 x 75 mm VESA with 2.25” Ball | 1
C-1 | Screw | - | SUS304 M4 x 12 mm Screw | 4
C-2 | Washer | - | M4 Washer | 4

Mounting 3 – Keyboard Mounting Installation (table)
No. | Component | RAM Mount Part Number | Description | QTY
A | Winmate Keyboard Adapter Plate (PN: 821009131600) | - | 4 VESA holes on the plate to device and 4 AMPS holes to RAM Ball | 1
A-1 | Screw | - | SUS304 M4 x 10 mm Screw | 4
A-2 | Washer | - | M4 Washer | 4
B | RAM Ball on the sloped part of the keyboard adapter plate | RAM-D-202U | 2.5" Round Base with 1.5" Ball | 1
B-1 | Screw | - | SUS304 M5 x 16 mm Screw | 4
B-2 | Washer | - | M5 Washer | 4
C | RAM Ball on the bottom part of the keyboard adapter plate | RAM-D-202U | 2.5" Round Base with 1.5" Ball | 1
C-1 | Screw | - | SUS304 M5 x 12 mm Screw | 4
C-2 | Washer | - | M5 Washer | 4
D | RAM Arm | RAM-D-201U | Arm for 1.5" Ball (Length: 5.6") | 1
E | RAM Ball on the sloped part of the keyboard adapter plate | RAM-D-202U | 2.5” Round Base with 1.5” Ball | 1
E-1 | Screw | - | SUS304 M5 x 12 mm Screw | 4
E-2 | Washer | - | M5 Washer | 4
F | Keyboard | - | - | 1

Accessories
Standard accessories

• M12 Power Cable (Model: PC-FM07) — 1.8 m M12 to power cable
• Adapter (Model: EA10681G) — 1.8 m, 100–240 V AC to 12 V 50 W DC
• M12 LAN Cable (Model: LN-FM07) — 1.8 m M12 to RJ45
• USB cable (Model: USC) — 0.3 m D-Sub 9 USB connector on dock to two standard USB host connectors
• Power Converter Cable (Model: PCC-FM) — terminal block to adapter converter cable
• Wi-Fi/BT Antenna (Model: WFA-FM07) — one dual band Wi‑Fi antenna
• RS232 Cable (Model: RSC) — 1.8 m standard 9-pin male com port cable
• CANBUS and DIDO Cable (Model: CD-FM07) — 1.8 m D-Sub 15 pin IP65 cable

Optional accessories

• WWAN Antenna (Model: WWA-FOM07)
• GPS Antenna (Model: GSA-FM) — 3 m GPS antenna
• Audio Cable (Model: AC-FM) — D-Sub 15 pin to audio out cable

Technical specifications

• Model: FM07
• Brand: Winmate
• Display: Projected Capacitive Multi-Touch, 7.0", 1024 x 600, 1000 nits
• Processor: Intel Celeron N3350 (1.1 GHz up to 2.4 GHz) default; Intel Pentium N4200 optional
• Memory: 4 GB default; 8 GB optional
• Storage: 1 x M.2 2242 SSD 128 GB
• Ethernet: 1 x Gigabit Ethernet (M12)
• Security: TPM 2.0
• OS: Windows 10 IoT Enterprise (64-bit) default; Linux Ubuntu 20.04 optional
• Wireless: WLAN, Bluetooth; WWAN 4G/LTE optional; GNSS GPS/GLONASS
• I/O: 2 x USB (via DB9), 1 x RS232/422/485, 1 x Gigabit LAN (M12), speaker, SIM slot, DIDO (5 DI / 3 DO), 2 x CANBUS
• Front control: Power button, 5 programmable function keys
• Power input: 9–36 V DC with ignition control; Max consumption 35 W
• Dimensions: 190 x 146 x 40 mm; Weight: 1.25 kg
• Operating temperature: -20 °C to 60 °C; Operating humidity: 10%–95% RH
• Shock & Vibration: MIL-STD-810G
• IP rating: IP65
• Certifications: CE, FCC, E‑Mark, MIL-STD-810G, IP65
