14" vehicle-mount computer FM14AD-V

12th Generation Intel® Core™Intel® Core i5-1235U13th Generation Intel® Core™

Product Overview
Winmate FM14AD-V is a 14" Windows vehicle-mounted computer with Intel® processor designed for warehouse logistics, fleet management and forklift operations. It provides MIL-STD-810H shock and vibration resistance, IP65 front protection, a 14" 1920×1080 PCAP touchscreen with optical bonding, wide power input 10–60V DC with ignition support, and VESA mount compatibility for vehicle and industrial installations.

Key Features

• 12th / 13th Gen Intel® processor family (selectable Core options)
• 14" 1920×1080 panel with Projected Capacitive (PCAP) multi-touch
• IP65 front sealing (water and dust protection)
• Wide power input 10–60V DC with ignition control
• Wide operating temperature: -30°C to 60°C
• VESA 75×75 mm mount support; fanless design

Certifications

• IP65
• MIL-STD-810H (shock & vibration)
• CE, FCC, IC (ICES-003)
• UL60950-1, EN60950-1, PTCRB

Product Details
Rugged design
Vibration- and shock-proof construction meeting MIL-STD-810H with IP65 front protection for reliable operation in harsh industrial and vehicle environments.

Display and usability
14" 1920×1080 PCAP touchscreen with optical bonding for improved sunlight readability, glove-capable touch and programmable function keys for simplified operation in vehicle workflows.

Performance
High-performance Intel® CPUs (hybrid core architectures in 12th/13th Gen family) provide enhanced graphics and connectivity for Industrial IoT, real-time data processing and integrated applications.

Operating environment
Designed for extreme temperatures including freezer use; supports frost- and condensation-free operation for cold chain and heavy-duty vehicle applications.

Standard / Optional Accessories
Standard accessories

• 1.8m power cable with fuse kit (FK-FMD-AD)
• 150W adapter with power cable (EA11301K)
• Power converter cable (PCC-FM)
• 1.8m DC power cable (PWC180-AD)

Optional accessories (examples)

• Magnetic multi-band combo antenna (VM10S)
• GPS & LTE MIMO combo antenna (VM9C)
• RS232 & audio cable, RS232 & DIDO cable, RS232 & CANBus cable
• Stylus kit, WWAN/GNSS antennas, IP65 LAN cable

Mounting Solutions / Example Mount Components
Mounting 1 – No Drill Solution (example)
No. | Component | RAM Mount Part Number | Description | QTY
A | RAM Clamp Mounts - forklift | RAM-D-247U-4 | Clamp base with 2.25" ball | 1
B | RAM Arm | RAM-D-201U | Arm for 2.25" ball (L: 8.375") | 1
C | RAM Ball (device side) | RAM-D-2461U | 75×75mm VESA with 2.25" ball | 1

Notes
Some images are samples and may differ from the actual product. Available installation methods depend on the purchased model.

Technical Specifications

• Display: 14.0"; 1920×1080; PCAP multi-touch; 700 nits; optical bonding
• Processor: Intel® Core™ i5-1235U (default) or i5-1335U (optional)
• Memory: 8GB (default); 16GB / 32GB optional
• Storage: 128GB (default); 256GB / 512GB optional
• Security: TPM 2.0
• OS: Windows 10 IoT Enterprise LTSC (64-bit) default; Windows 11 IoT Enterprise LTSC optional
• Wireless: WLAN, Bluetooth; WWAN LTE/5G (optional); GNSS (optional)
• Camera: Front 2 MP
• I/O: USB-C (USB 3.0), USB 2.0, 2×RS232/422/485, Gigabit LAN (optional PoE), Audio, Micro SD, Dual-Nano SIM, DIDO, CANBus (options)
• Mechanical: 342×225×52 mm; 2.5 kg; VESA mount; fanless
• Environment: -30°C to 60°C operating; 5%–90% RH non-condensing; IP65; MIL-STD-810H; EN62262 IK07; ESD per EN61000-4-2
• Power: 10–60V DC with ignition control; optional 2400mAh UPS (~1 h backup)
