Diesel skid steer loader FM280T

Overview
The FM820T skid steer loader is a compact machine engineered for medium to high-intensity work. It provides maneuverability in confined spaces, a quick‑attach system for multiple implements and continuous rated power suitable for construction, municipal, industrial yard and light agricultural operations.

Key features

• Compact footprint with bucket for operation in constrained areas (3815 × 1880 × 2122 mm)
• Flat bucket 0.44 m³ and rated load 1,400 kg to improve loading cycles
• Discharge height (full lift) 2,664 mm for efficient material transfer
• WEICHAI engine 74 kW / 100 HP (National III) providing continuous rated power
• Hydraulic flow 85 / 135 L/min compatible with a range of attachments
• Two‑speed travel (10 / 20 km/h) for transport and maneuvering
• Skid‑steer chassis with quick‑attach system for sweepers, crushers, grapples and augers

Applications

• Construction site loading and material handling
• Municipal maintenance and landscaping
• Industrial yard operations and logistics
• Light agricultural loading and cleaning

Recommended models

• FM220 Skid Steer Loader
• FM235X Skid Steer Loader
• FM260X Skid Steer Loader

Notes
Page shows inconsistencies: some sections reference model FM280T and a rated load of 1,200 kg while the specifications table lists FM820T with 1,400 kg. The technical data below follow the specifications table.

Technical specifications

• Overall size with bucket (mm): 3815*1880*2122
• Overall size excluding bucket (mm): 3045*1852*2122
• Working height - full lift (mm): 4354
• Articulation height - full lift (mm): 3404
• Discharge height - full lift (mm): 2664
• Discharge distance - full lift (mm): 392
• Standard bucket: 72
• Flat bucket capacity (m³): 0.44
• Overall weight (kg): 3732
• Rated load (kg): 1400
• Tyre size: 12-16.5
• Dual speed driving speed (km/h): 10/20
• Engine brand: WEICHAI
• Engine power (kW/HP): 74/100 (National III)
• Hydraulic flow (L/min): 85/135
