Diesel forklift CPCD35

ride-onfor the construction industryfor warehouse

Overview
The FMAN 3.5-ton CPCD35 diesel forklift is designed for high-intensity material handling operations. With a rated load of 3500 kg, it is suitable for loading, unloading and internal transfer of large quantities of goods, machinery parts and industrial materials in warehousing, logistics, manufacturing and building-materials distribution. The machine features a reinforced structure that provides enhanced strength and impact resistance for stable operation under heavy lifting and continuous duty.

Power system
The powertrain uses a 4D27G31 (Xinchang) diesel engine with a rated output of 36.8 kW at 2500 r.p.m and a rated torque of 156 Nm at 1700–1900 r.p.m. The engine delivers stable and reliable output with strong low-speed torque response under heavy loads while maintaining fuel efficiency.

Dimensions & design
Overall dimensions (without forks): 2765 × 1230 × 2090 mm. The chassis and body layout optimise maneuverability in narrow aisles while preserving load-bearing capacity. Component arrangement facilitates routine maintenance to reduce service time and downtime.

Performance
The FMAN CPCD35 combines reliable power, stable load handling and operational economy, improving material handling efficiency and equipment availability in demanding industrial environments.

Technical data
Item: Model: UNIT: CPCD35; Rated load: kg: 3500; Self weight (without load): kg: 4600; Engine - Model: 4D27G31 (Xinchang); Engine - Rated output: kW/r.p.m: 36.8/2500; Engine - Rated torque: Nm/r.p.m: 156/1700-1900; Overall dimensions (L × W × H, without forks): mm: 2765 × 1230 × 2090.

Features / Technical specifications

• Model: CPCD35
• Rated load: 3500 kg
• Unloaded weight (self weight): 4600 kg
• Engine model: 4D27G31 (Xinchang)
• Rated power: 36.8 kW @ 2500 r.p.m
• Rated torque: 156 Nm @ 1700–1900 r.p.m
• Overall dimensions (L × W × H, without forks): 2765 × 1230 × 2090 mm
• Reinforced structure for enhanced strength and impact resistance
• Designed for heavy-duty warehouse, logistics, manufacturing and building-materials operations
