Helical gear pump MPB1000

waterglycol waterfor chemicals

Product Overview
The magnet-drive MPB1000 micro magnetic gear pump provides a fully sealed pump chamber with no pulsation, no leakage and low noise. Compact and high-performance, it is designed for precise metering and continuous transfer. Typical operating range: flows up to 100 L/min (model-dependent) and differential pressures from 0.5 to 5 bar for larger models.

Key Features

• No-pulse accurate delivery
  Helical gears provide continuous, pulse-free fluid transport. With servo or stepper motor control, delivery accuracy can reach ±0.5%.
• Strong suction capability
  Stable conveyance and good suction performance allow reliable delivery of low-viscosity liquids at higher pressure.
• Leak-free operation
  Magnetic coupling with static O-ring sealing (FKM or PTFE) isolates the pumped medium to eliminate external leakage.
• Low noise
  Torque transmission via magnetic coupling avoids mechanical contact; helical gear design reduces friction, impact and vibration.
• Long service life
  High-performance engineering materials and precision manufacturing extend operational lifetime.

Description
The MPB1000 is part of the MPB series of micro magnetic gear pumps. Standard gear material is PEEK; housing and shafts are available in 316L stainless steel and other options. Power is transmitted via internal/external magnetic coupling to ensure leak-free operation. The pump suits applications requiring precise flow control, high purity and non-contamination in chemical dosing, lubrication, cooling and laboratory systems.

Compatible media (examples)
Deionized water, methanol, urea solution, kerosene, additives, lubricating oil, caustic solutions, ammonia solution, cobalt solution, dialysate, ethylene glycol, freon, ink, glycerin, phenolic resin, curing agent, fragrance oils, fluorinated liquids.

Model Specification (table)
Model: MPB series
Pump series: MPB = Rubber O-ring Seal
Model / Displacement: MPB600 = 15 ml/rev (max flow 45 L/min)
MPB1000 = 33 ml/rev (max flow 100 L/min)
Pump body materials: A: 304; B: 316L; C: PPS; D: Hastelloy; E: Titanium alloy
Gear / Shaft options:
A: Gear PEEK + shaft 316L
B: Gear PEEK + shaft ceramic
C: Gear PEEK + shaft tungsten steel
D: Gear PEEK + shaft titanium alloy
E: Gear 316L + shaft 316L
Inlet/Outlet thread: E = chuck

Technical Parameters (table)
Common ranges: Temperature: -40℃ ~ 100℃
Recommended inlet filter: 400 mesh
Maximum inlet vacuum level: -0.85 bar

MPB003: Displacement 0.1 ml/rev; Flow 0.3 L/min; Viscosity 0–3000 cps; Pressure diff 0–20 Bar; Noise (4000 RPM) < 60 dB
MPB010: Displacement 0.28 ml/rev; Flow 1.0 L/min; Viscosity 0–3000 cps; Pressure diff 0–20 Bar; Noise (4000 RPM) < 60 dB
MPB015: Displacement 0.35 ml/rev; Flow 1.5 L/min; Viscosity 0–3000 cps; Pressure diff 0–20 Bar; Noise (4000 RPM) < 60 dB
MPB030: Displacement 0.9 ml/rev; Flow 3.0 L/min; Viscosity 0–3000 cps; Pressure diff 0–20 Bar; Noise (4000 RPM) < 60 dB
MPB060: Displacement 1.41 ml/rev; Flow 6.0 L/min; Viscosity 0–3000 cps; Pressure diff 0–20 Bar; Noise (4000 RPM) < 60 dB
MPB075: Displacement 1.7 ml/rev; Flow 6.0 L/min; Viscosity 0–3000 cps; Pressure diff 0–20 Bar; Noise (4000 RPM) < 60 dB
MPB100: Displacement 3.6 ml/rev; Flow 10 L/min; Viscosity 0–3000 cps; Pressure diff 0–20 Bar; Noise (4000 RPM) < 60 dB
MPB150: Displacement 5.4 ml/rev; Flow 15 L/min; Viscosity 0–3000 cps; Pressure diff 0–20 Bar; Noise (4000 RPM) < 60 dB
MPB200: Displacement 6.6 ml/rev; Flow 20 L/min; Viscosity 0–3000 cps; Pressure diff 0–20 Bar; Noise (4000 RPM) < 60 dB
MPB350: Displacement 12 ml/rev; Flow 35 L/min; Viscosity 0–3000 cps; Pressure diff 0–20 Bar; Noise (4000 RPM) < 60 dB
MPB600: Displacement 15 ml/rev; Flow 45 L/min; Viscosity 0–12000 cps; Pressure diff 0–5 Bar; Noise (2000 RPM) < 60 dB
MPB1000: Displacement 33 ml/rev; Flow 100 L/min; Viscosity 0–12000 cps; Pressure diff 0–5 Bar; Noise (2000 RPM) < 60 dB

Technical features / specifications

• Drive type: Magnetic drive (internal/external magnetic coupling)
• Seal: Static O-ring (FKM or PTFE)
• Gear material: PEEK (standard)
• Shaft materials: 316L stainless steel, ceramic, tungsten steel, titanium alloy (configurable)
• Pump body options: 304 / 316L / PPS / Hastelloy / Titanium alloy
• Displacement range: 0.1 ml/rev to 33 ml/rev (model-dependent)
• Flow range: 0.3 L/min to 100 L/min (model-dependent)
• Viscosity capability: up to 12,000 cps (model-dependent)
• Operating temperature range: -40℃ to 100℃
• Pressure capability: up to 20 Bar (small models), up to 5 Bar (600/1000 models)
• Recommended inlet filter: 400 mesh
• Maximum inlet vacuum level: -0.85 bar
