AC synchronous motor and Stepper motor
• Unidirectional and bidirectional
• Power supply: from 12 to 230Vac
• Running torque: from 0,08 to 4 Ncm
• Output shaft speed: from 375 to 600 rpm
Stepper Motor
• Bipolar stepper motor
• Supply voltage: 12 Vdc
• Full step: 24
• Running torque: fix at 4 Ncm among motors and gearmotors
|
|
saia synchronous motor
Dimensions (mm) Ø 36x21
Step angle (°) 7.5/15
Holding torque (cNm) 1.0-1.9.
Detent torque (cNm) 0.22-0.36
Resistance per winding
bipolar/unipolar 6 V (Ohm) 18.5/28
12 V (Ohm) 100/120
24 V (Ohm) 460/500
Gear combination A, D, M, B, F, V
|
|
Synchronous motors are often used in applications where precise speed is critical to the application. Shaded pole (asynchronous) motors offer higher levels of output power than synchronous motors however speed will vary under load.
The most important step lies in the accurate definition of the work that you require the motor and gearbox to perform. The selection of a suitable motor and gearbox can only be made if the torque and speed can be defined. Of these two parameters, torque is probably the most difficult to identify - please contact us if you need help.
|
|
|
Hysteresis Synchronous Motors are designed to meet both Military and Commercial requirements. These AC Motors range from size 8 to 44. This type motor is utilized where constant speed and smooth operation are necessary.
|
|
ASTRO synchronous motor ASM
- starting and direction of rotation-stably
- synchronous, load-independent number of revolutions
- blockierfest briefly
- 1-polig reversable
- high efficiency
- noiseless run
- high self retaining moment
- maintenance-free
Overall lengths
ASM 24/26 = 49mm
ASM 44/46 = 69mm
ASM 84/86 = 109mm
Terminal box execution = 33mm longer
Engine system
4-polig with 1.500Upm (50Hz), 1800Upm (60Hz)
with 6 pins with 1.000Upm (50Hz), 1200Upm (60Hz)
Rated voltages = 1~24V to 3~500V
Continuous operation S1 (special modes of operation possible)
Self retaining moment in the dead condition
Wärmeklasse B
Coil windings = to 130°C
Ambient temperatures = -15C to 40°C
Enclosure = IP40, IP54, IP55
Basic parts = plastic ones or aluminum pressure pouring
Kind of connection = cable, braid or terminal box connection
|
|
ASTRO actuator with spur gear ASM ST
|
|
Slow speed synchronous motor
Applicable Condition
Ambient temperature: -25℃ +40℃(G)
Air pressure: 74.8KPa(2500m)
Relative humility: 90%-95%
|
|
Reversible Synchronous Motor
Specifications:
Rated voltage: 24, 110,220V
Power frequency: 50/60Hz
Rotor speed: 500-600RPM
Output RPM: From 1 to 60 RPM
Torque: 50 kgf/cm at 1 RPM
Rotation: CW, CCW, Reversible, Bi-direction
Operating temperature: -10o ~ +70o C
Insulation strength: AC1500V, 1 min.
Insulation class: B class
Input power: 5~6W
Feature:
Lower price with high toque performance.
It possesses similar features to Oriental or Servo motor.
The support wrapped/fixed style gear design.
High magnetic rotor design: Material- MQ serial magnet steel (ND-Fe-B)
Precision gear set design: Using Swiss 'Mikron' gear hobbing machine
|
|
Reversable Synchronous Motor
Specifications:
Rated voltage: 24, 100, 110-120, 200-240V
Power frequency: 50/60Hz
Input power: 3~6W
Number of poles: 12 P
Rotor speed: 500 - 600 RPM
Output RPM: 1~200 RPM
Torque: 40 kgf/cm at 1 RPM
Rotation: CW, CCW, FREE, Reversible, Bi-direction
Operating temperature: -10o ~ 60o C
Insulation strength: AC1500V-1Min
Insulation class: A, B class
Lead wire: 1007XAWG22 x 200 m/m
Input power: 5~6W
|
|
Reversable Synchronous Motor
Specifications:
Rated voltage: 24, 100, 110-120, 220-240 V
Power frequency: 50/60 Hz
Input power: 3~6W
Number of Poles: 12P
Rotor speed: 500- 600 RPM
Output RPM: From 1 to 99 RPM
Torque: 88 kgf/cm at 1 RPM
Rotation: CW, CCW, Reversing, Reversible, Bi-direction
Operating temperature: -10o ~ 60o C
Insulation strength: AC1500 V-1Min
Insulation class: A, B class
Lead wire: 1007XAWG#22 x 200m/m
Input power: 5~6W
|
|
| ... products without technical information |
| |
|
These low-pole AC servo motors of the ECOSPEED series stand out due to extremely low torque ripple at low speed. Torque from 1 - 26 Nm. Flange dimensions 60 mm, 80 mm, 110 mm, 130 mm. Rated speed depending on series between 1500 and 5000 rpm. Available with incremental encoder or absolute value encoder. Holding brakes from 0.5 - 10 Nm (optional). Certified version according to ATEX directive 94/9/EG for use in hazardous locations. Also available as hollow-shaft built-in motor. Approvals: UL/CSA, CE.
|
|
MSK Series
This series offers complete scalability, with performance options for standard and more challenging applications. The compact construction with increased torque density provides a costomer-orriented range of size and performance.
|
|
Meeting stringent requirements in terms of response, precision and excellent power-to-size ratio.
The motor sizes have been carefully graded and offer rated torques from 0.8 to 64 Nm (0.25 to 10.0 kW) and peak torques of up to 191 Nm. As a result, finding the optimum motor for any drive task is easy.
|
|
|
Our AC synchronous servomotors have a very high power density and enable highly dynamic positioning drives with an excellent price/performance ratio. For maximum flexibility, the servomotors are compatible with the standard servo connection dimensions. The AC synchronous servomotors are equipped with an absolute sensor system: SinCos® Singleturn (SRS, SKS) or SinCos® Multiturn (SRM, SKM). The encoder system with the Hiperface® interface enables auto-initialisation of the motor and current controller parameters. This greatly simplifies the commissioning procedure of the drive system.
|
|
Technical Data: FMD motors
- Nominal torque: 0.5 Nm to 68 Nm
- Rated speed range: 2000 to 6000U/min
- Flange dimensions: 58, 70, 92, 115, 142 and 190mm
- Protection class: IP65
|
|
Brushless three-phase synchronous servo motors with permanent magnets.
- Static torque 0.1 to 115 Nm.
- Particularly high power density
- Large rotational speed control range
- High dynamics and precision
- Maintenance-free
- Optionally with brake
Customer-specific solutions: high rotational speeds, special flanges, special shafts etc.
|
|
|
|
|
|
DSD - the servo motors for highly dynamic applications
The six installation sizes for the DSD-range of Baumüller offer a suitable solutions for almost every application in the automation.
The servo motors for highly dynamic applications with the highest requirements of acceleration capacity and the best start-stop qualities, such as for:
packaging machines
textile machines
plastic machines
handling machines
special machines
small robots
DSD 28-100 - Dynamic Motors
high torque accuracy
high speed
almost no cogging effect
compact frame size with high power density
maximum dynamic response due to excellent torque - inertia ratio
smooth housing surface – not easily soiled
sleek, uniform housing
permanent field synchronous servo motors
main connection via terminal box or connector (DSD 28 - 45 only via connector)
IP44, other protection type on request (DSD 28 - 36)
IP65 non-ventilated, IP54 surface-ventilated with fan (DSD 45 - 100)
encoders: resolver 2-pole, SinCos-encoder (optional)
more encoders available on request
all types optionally with brake
|
|
While smaller in size, gives highest dynamics and output power.
The servomotors presented here are only a small part of the wide Groschopp product range.
|
|
The LSH Servomotor - the power pack
Nominal torque 0,2 Nm up to 20 Nm
Based on the new winding technology, the so-called concentrated winding, the new LSH generation of motors improves power density by between 30% and 70% relative to conventional technologies. For the user that means as much as a 100% improvement in dynamics, and more compact installation combined with smooth running.
The LST-Servomotor - the versatile one
Nominal torque 0,1 Nm up to 24 Nm
Featuring conventional winding technology, the LST motor combines all the advantages of a 6-pole synchronous servomotor.
* Well suited to speeds up to 9000 rpm. Special windings are possible on request.
* High overload capacity even at standstill based on efficient heat distribution in the stator packet.
* Increased rotor moment of inertia for torque adaptation.
|
|
MSK Series
This series offers complete scalability, with performance options for standard and more challenging applications. The compact construction with increased torque density provides a costomer-orriented range of size and performance.
|
|
| ... products without technical information |
| |
AC synchronous geared motor with flat transmission ASM fG 05 or 20
|
|
AC ASTRO synchronous geared motor with worm gear
ASM SSG
|
|
ASTRO synchronous motor with Stirnradgeriebe ASM SG
- starting and direction of rotation-stably
- synchronous, load-independent number of revolutions
- blockierfest briefly
- 1-polig reversable
- high efficiency
- noiseless run
- high self retaining moment
- maintenance-free
Overall lengths
ASM 24/26 SG = 89,5mm
ASM 44/46 SG = 109,5mm
ASM 84/86 SG = 149,5mm
Terminal box execution = 33mm longer
Engine system
4-polig with 1.500Upm (50Hz), 1800Upm (60Hz)
with 6 pins with 1.000Upm (50Hz), 1200Upm (60Hz)
Rated voltages = 1~24V to 3~500V
Continuous operation S1 (special modes of operation possible)
Self retaining moment in the dead condition
Wärmeklasse B
Coil windings = to 130°C
Ambient temperatures = -15C to 40°C
Enclosure = IP40, IP54, IP55
Basic parts = plastic or aluminum pressure pouring
Kind of connection = cable, braid or terminal box connection
|
|
ASTRO gear motor with flat transmission ASM SG01
|
|
ASTRO synchronous geared motor with planetary gear ASM PG
|
|
|
|
