The GmCLab is the perfect addition to any laboratory workbench. This compact and highly dependable personal mini-centrifuge allows to quickly separate particles from the supernatant in a solid-liquid mixture or spin down liquids to the bottom of a tube.
Gilson’s GmCLab is extremely comfortable to use and features a transparent lid that can be fully opened to an angle of 160° to allow ample access to the tubes. The pinch-type connector makes it easy to change the rotor in just a few seconds. With its small footprint GmCLab will fit on even the most crowded bench.
What type of containers can be used with the GmCLab®?
– Round or conical bottom shape 1.5/2.0 ml microtubes
– Strips of 8-PCR (0.2 ml) tubes
– Single PCR (0.2 ml) tubes
GmCLab comes with:
– 1 GmCLab module with an 8 position rotor for 1.5/2.0 ml microtubes
– 1 User’s Guide (English only)
– A 2 strip rotor for 8-PCR(0.2ml) tubes
– 8 micro-tubes of 1.5 ml
– 2 strips of 8-PCR(0.2 ml) tubes
– CE certificate (except for US model)
– One-year warranty
|
|
|
This versatile 30 place centrifuge is incomparably fast and offers a wide range of applications due to the extensive choice of different rotors. The sophisticated and optimal structured operation panel is the result of an ergonomic survey. This combination of programmable applications, rotor variety and ergonomic control panel makes your daily routine lab work easier and your unique application possible. The Centrifuge 5430 can be equipped with up to 8 different rotors, which can accommodate tubes such as 1,5/2,0 ml tubes, 15 ml and 50 ml Falcon tubes or MTP plates. The Centrifuge 5430 achieves a maximum g-force of over 30.000 x g.
|
|
|
|
|
|
CEPA centrifuges are characterized by their ability to process many times the volume of their tubular bowl. Fluid mixtures are fed into the bottom of the rapidly rotating separation chamber. Solids are retained, while liquid components are expelled from the top of the chamber through a collection tray. For liquid-liquid separations, two collection trays are used. The retained solids cake is dry and densely packed by the high G-forces of the CEPA centrifuge. Plastic bowl liners are available for models LE, Z41 and Z61 to facilitate cell paste removal.
The optimum size of a centrifuge for a given application depends on the properties of the process liquid. Typical process volumes specified for each centrifuge are approximate. Contact NBS for a no-obligation consultation regarding your specific application.
TYPICAL APPLICATIONS
- Harvesting biomass
- Clarifying process liquids
- Separating liquid products
- Fractionation of human blood
- Animal blood processing
- Bioremediation
- Processing of granular, crystalline and fibrous suspensions
- Separation of filterable and non-filterable sludges
FEATURES AND BENEFITS
- Rapid separations.
- Consistent performance.
- Range of models facilitate scale-up.
- Simple to set up, easy to use and rapidly cleaned with minimal downtime.
- No fragile membranes to install.
- No replacement membranes, or costly disposables
- Small footprint saves valuable space
- Enclosed models available to help control aerosols and ambient gas and attain quieter operations
- For mixtures with extremely high solids concentrations, drum centrifuges can be supplied
- Powerful 3-phase electric motors (in models Z41 - Z101) provide rapid acceleration, and quieter operation
- Permanently lubricated oversized head bearings maintain long service life
|
|
Whether you need a refrigerated or non-refrigerated centrifuge for low, medium or high-throughput applications, one of these bundles will definitely suit your requirements.
The Cell Culture Centrifuge Bundles are optimized for swingbucket rotor applications in standard 15 ml and 50 ml Falcon® tubes.
Cell Culture Centrifuge Bundle includes
* Centrifuge 5702, 5804/ 5804 R or 5810/ 5810 R
* Swing-bucket rotor incl. buckets
* Four adapters for 15 ml Falcon® tubes (two sets of 2)
* Four adapters for 50 ml Falcon® tubes (two sets of 2)
The Clinical Centrifuge Bundle is optimised for Centrifuge 5702 R with adapters for 13 mm and 16 mm blood collection tubes or urine tubes.
Clinical Centrifuge Bundle includes
* Centrifuge 5702 R
* Swing-bucket rotor A-4-38 incl. round buckets
* Four adapters for 13 mm blood collection tubes or urine tubes (two sets of 2)
* Four adapters for 16 mm blood collection tubes or urine tubes (two sets of 2)
|
|
Gentle separation/perfusion system providing separation forces up to 320 g. Two systems are available - CENTRITECH® LAB-II and CENTRITECH® CELL.
Benefits
-Gentle cell handling coupled with removal of dead cells, offering higher viability and productivity
-Closed system with pre-sterilized disposable inserts
-Eliminated need for CIP/SIP
-Automated continuous separation
-Ergonomic design suited to modern laboratory environments
-Full scalability for perfusion bioreactors (5-3000 liter) or cell harvest (5-600 liter)
|
|
|
|
|
|
Laboratory centrifuge for continuous separation of two liquids, clarifying of liquids from solids, emulsifying of several liquids, fraction of plasma protein, concentration and extraction of viruses and bacteria as well as further fields of application.
Function
CEPA centrifuges are characterized by their ability to process many times the volume of their tubular bowl. Fluid mixtures are fed into the bottom of the rapidly rotating separation chamber. Solids are retained, while liquid components are expelled from the top of the chamber through a collection tray. For liquid-liquid separations, two collection trays are used. The retained solids cake is dry and densely packed by the high G-forces of the CEPA centrifuge.
Benefits
Quick separation
Continual capacity
Easy installation and handling
The results can be correlated to production centrifuges of type Z 41 to Z 101
Favourable maintenance
Small space of installation saves valuable room
Deliverable in closed execution
Technical data
Type/Model: LE / GLE
Throughput l/h*: 30
rpm: 15.000 to 40.000
G-force max.: 40.000
geometric content: 0,25 l
* The max. throughput is related to water.
|
|
|
A powerful, easy-to-use solution, the Sorvall RC12BP? low-speed refrigerated centrifuge allows you to manufacture blood components quickly and cost-effectively while ensuring product quality, safety, and GMP compliance.
|
|
| ... products without technical information |
| |
|
|
|
|
In the centrifugal drum there is a hydraulically activated sliding floor which moves in an upwards and rotational direction. The continuously fed materials first fall through the inlet funnel into the drum and land in a circle around the base of the drum wall.
The programmed sliding floor pushes the material in set cycles through the specifically designed bar screen integrated into the drum wall.At this point the material is separated into solids and fluids. The dried material is carried over the edge of the drum by the upwards push, bounces off the oil scraper ring on the housing wall and exits the centrifuge down through the tapered chip ejection funnel. The projected fluid flows off to the side along the fixed retaining wall down the diagonally placed outlet gulley under the drum into the adjacent holding tank.Subsequent material and the constant outwards motion of the sliding floor prevents the bar screen from sticking or getting blocked. The centrifuge's self-cleaning concept reduces cleaning work to the absolute minimum.
The sliding technology saves staff having to regularly clean the drums as they normally would. The machine housing stands on several oscillating components which ensure the centrifuge runs quietly.
|
|
Series AS
Operation directly at the processing machine possible. Capacity per hour 120 kg – 1 t. Fully automatic, continuous de-oiling of metal turnings.
Series KSE
Robust Machines for systems for throughput of 850 l/h – 12.000 l/h. Fully automatic continuous de-oiling of short chips.
Series VZ
Charging load 100 kg with 8 batches/h – 200 kg with 6 batches/h. Fully automatic continuous batch wise de-oiling of chips.
|
|
|
|
|
|
The PERMOLEX-POLAR Centrifuge
The continously operating centrifuge for the recovery of coolants when swarf and grinding sludge are processed.
ADVANTAGES:
- Suitable for swarf of all common metall classes and grinding sludge
- Very low residual moisture achievable
- High wear resistance due to manganese lining
- Continuous and fully automatic operation
- Low maintenance and service cost
- Very high operational reliability
- Short payback period
FUNCTION:
The metal swarf mixed with coolants or grinding sludge are conveyed by means of a suitable controllable conveying device. The metering screw (optional for K41 – K101) in the charging hopper of the centrifuge has the task to feed the materials evenly into the drum. According to the kind of swarf, coolant and continuity of the swarf flow to the centrifuge the use of the metering screw can be dispensed with. For swarf tending to get stuck or to stick (e. g. aluminium) the use of the metering device is basically recommended.
Due to the particular drum design and the effect of the centrifugal force swarf is spun against the inner wall of the centrifugal drum and is then slowly pushed upward within the drum by succeeding swarf. The throughput capacity of the centrifuge and thus the dwell time of the swarf in the drum are determined by controlling the conveying speed of the conveyor.
At the largest drum diameter the coolant passes out of the drum through an exchangeable bar screen into the spinning off area.
The dried swarf is pushed over the upper drum rim. Outside it is spun against an exchangeable manganese rebounding ring. Swarf and coolant are separately led out of the centrifuge.
|
|
|
|
|
|
Cleaning centrifuge for continuous separation and cleaning of cooling lubricants and washing fluids.
The liquid to be cleaned is supplied by a connection in the centre of the cover and reaches the bottom of the application vessel through a conducting cone. By accelerating the liquid, the sedimentation movement is immediately initiated for separating all specifically heavy solid impurities such as grinding and turning chips. The cleaned liquid rises upward and is conducted away via a skimming pipe. Due to the high-speed acceleration, the cleaned liquid rises up to 3 metres through the skimming pipe. The solid material in the application vessel is manually lifted out.
The RZ 400 is specially designed for separating non-emulsified oil from cooling lubricant emulsions or saturated washing fluids. This is a problem, for example, with hydraulically controlled automated machines and processing centres or washing systems. In this case, the two liquid phases are separated and the heavier solid material is collected in the application vessel. The liquid phases are carried out without pressure and have to be collected in a tank. The solid material in the application vessel is manually lifted out.
|
|
Extremely robust industrial batch-processing centrifuges for de-oiling, oiling, washing and drying chips and parts. Available sizes for batches from 35 - 450 kg.
Standard equipment: Removable, perforated application vessel, no-wear generator brakes, motor protection (thermal), unbalance switch, automatic cover locking, signal lamps, timer.
Benefits:
- Robust industrial centrifuge
- Easy installation and handling
- Low maintenance cost
- Can be used in a Flexomat system (fully automatic
operation)
- Diverse uses
- Available as immersion centrifuge (oiling, wetting)
|
|
- Simple handling
-Safe performance
-Little space required
-Ready to connect up to size C6; control is directly mounted on machine.
-Individual solutions due to specially designed receivers for the part to be centrifuged.
-Versatile use for drying, de-oiling, oiling, coating, rinsing …
|
|
| ... products without technical information |
| |
Description
- stainless steel, vertical axis concept
- device to control formation of magma or syrup at the required Bx, Qz
- new design of bell distributor for better vibration camping
- two different lubrification systems: oil pressure and grease only for the levels of roll-and-ball-bearings;
- high-power belt drive,new trasmission systems mechanical brake
- motor and outlets positioning accordino to customer requirements
Features :
*Power: AC electric motor 110 Kw, 4 poles.
*Standard voltage: 380 V + 50 Hz or 440 V + 60 Hz
*Overal dimensions: 2,500 x 2,300 x 2,370 mm
*Weight: 5,6 tons
|
|
|
|
|
|
Manual Clean Centrifuges
Sanborn Technologies offers one of the largest selection of manual-clean centrifuges in the industry. These centrifuges are common in applications with moderately low solids concentrations where the solids are cleaned out of the centrifuge periodically by hand. Designs range from liquid-liquid and liquid-solid (2-phase separators) to liquid-liquid-solid (3-phase separators) in both basket-type and high-speed disc configurations.
Automatic Discharge Centrifuges
Automatic discharge centrifuges are found in applications with moderate to high solids concentrations where the solids need to be discharged frequently from the centrifuge. Designs include a range of 2-phase and 3-phase separators in both basket-type and high-speed disc configurations.
Tank Mounted Systems
We offer a wide range of tank mounted systems to fit the most common machine tool applications. These systems range from single tank and pump configurations to sophisticated custom-designed tank, pump and control systems with multiple centrifuges and coolant chillers.
High-Speed Disc Centrifuges
Sanborn Technologies' Integrated Fluid Recovery (IFR) systems, utilizing high-speed disc centrifuges, have been a central part of our product offerings for over 25 years. These IFR systems include multiple unit operations in a single compact system for complete maintenance of machine tool sumps. Models range from the mobile Puritan, designed to service a single sump at a time, up to the Patriot central system, complete with clean/dirty tanks and automated coolant make-up. The Pioneer is designed for batch central systems and can be mobile.
|
|
