Biotechnology centrifuge CF-TLR25

laboratorybenchtoprefrigerated

Short description
CF-TLR25 is an intelligent tabletop refrigerated high-speed centrifuge for molecular biology and clinical laboratories. It offers tool-free rapid rotor installation and removal, a 7-inch HD LCD touch control and an advanced control system for program management and data traceability. Suitable for protein, DNA/RNA, cell separation and routine clinical workflows.

Features

• Rapid rotor installation and removal without screws or tools.
• 7-inch HD touch screen control with simultaneous display of setup and running parameters.
• Large-capacity data storage: months of run data and fault records; supports hundreds of custom programs with detailed descriptions.
• Advanced control functions: step/ladder centrifugation, scheduled start, sample ID, curve mode, program mode and English/Chinese language switching.
• User management and access control to prevent unauthorized changes.
• Automatic door lock with single-button open/close operation.
• Multiple rotor options available; maximum speed up to 25,000 rpm; can replace floor high-speed units in many applications.
• Safety protections: rotor identification, imbalance detection, over-temperature and over-speed protection.

Specifications
Model: CF-TLR25
Max. Speed: 25,000 r/min
Max. RCF: 44,720 x g
Max. Capacity: 6 × 100 ml
Speed Accuracy: ±20 rpm
Time Setting Range: 1 min to 99 min 59 s
Temperature Setting Range: -20°C to 40°C
Temperature Accuracy: ±2°C
Compressor: Non-CFC unit (R404a)
Noise: ≤62 dB(A)
Power Supply: AC 220V ±22V 50Hz 18A
Wattage: 1500 W
Dimension (WxDxH): 710 × 560 × 450 mm
Package Dimension (WxDxH): 1022 × 712 × 630 mm
Net Weight: 95 Kg

Rotor information
Host: Model CF-TLR25 — Host — RPM 25000 — RCF 50560 — DESC: LCD touch
NO.1: Angle rotor — RPM 25000 — RCF 44720 — Capacity 12 × 1.5 ml
NO.2: Angle rotor — RPM 14000 — RCF 21912 — Capacity 12 × 15 ml (sharp bottom)
NO.3: Angle rotor — RPM 19000 — RCF 36715 — Capacity 12 × 10 ml
NO.4: Angle rotor — RPM 16500 — RCF 28854 — Capacity 6 × 50 ml
NO.5: Angle rotor — RPM 15000 — RCF 24150 — Capacity 6 × 50 ml (sharp bottom)
NO.6: Angle rotor — RPM 16000 — RCF 27762 — Capacity 8 × 50 ml
NO.7: Angle rotor — RPM 23000 — RCF 50560 — Capacity 24 × 1.5 ml
NO.8: Angle rotor — RPM 19000 — RCF 38987 — Capacity 48 × 1.5 ml
NO.9: Angle rotor — RPM 13500 — RCF 21800 — Capacity 6 × 100 ml
NO.10: Angle rotor — RPM 20000 — RCF 35328 — Capacity 6 × 30 ml

Technical specifications

• Model: CF-TLR25
• Max speed: 25,000 r/min
• Max RCF: 44,720 x g
• Maximum sample capacity: up to 6 × 100 ml (varies by rotor)
• Temperature control range: -20°C to 40°C (accuracy ±2°C)
• Control/interface: 7-inch HD LCD touch screen; program memory and user management
• Power: AC 220V ±22V 50Hz, 18A; 1500 W
• Net weight / Dimensions: 95 kg; 710 × 560 × 450 mm (WxDxH)
• Safety features: rotor identification, imbalance detection, over-temperature and over-speed protection, automatic door lock
