SUMMARY:
- Full hot air convection
- 4 Zone control
- PCB width up to 365mm
- Glass Top Design
- Built-inTemperature profile
- WComputer Control
Autotronik BS3020 is a high performance full hot air convection reflow soldering system
with computers control which can handle boards up to 365mm width with less than +/-2 centigrade degree temperatures gradient.
|
|
SUMMARY:
- Full hot air convection
- 4 Zone control
- PCB width up to 365mm
- Glass Top Design
- Built-inTemperature profile
- WComputer Control
Autotronik BS3020 is a high performance full hot air convection reflow soldering system
with computers control which can handle boards up to 365mm width with less than +/-2 centigrade degree temperatures gradient.
|
|
Temperature test chambers with forced convection and individual programming
BINDER M series:
Because of its individual programming options and ability to operate at maximum temperatures up to 300 °C, the M series is ideally suited for materials testing and aging tests. The heavy-duty air turbine and a programmable exhaust ventilation flap provide rapid heating-up and ensure that the test temperature is maintained absolutely precise at all levels, with minimal spatial fluctuations; performance as never before.
|
|
|
The Despatch LBB oven features a combination of horizontal and vertical airflow that offers excellent temperature uniformity at a moderate price. It is recommended for a variety of laboratory and production applications including drying, curing, annealing and materials testing.Every LBB oven is UL and C-UL listed, and receives a thorough performance test before shipping.
|
|
Heating ovens with forced convection
BINDER FED series:
The FED series is a true all-rounder. It has a virtually unlimited capacity and is at the same time particularly adaptable to the specific requirements of a large variety of testing applications. The enhanced time functions and the digitally controlled air turbine can be used to adjust ideal temperature parameters and recirculation air conditions.
|
|
|
|
|
|
Carbolite’s LGP range of industrial batch ovens sets the standard for a wide range of industrial processing applications
The ovens provide excellent performance and reliability
Standard chamber capacities range from 500 – 14,000 litres, at temperatures up to 250°C, 425°C and 625°C
A long working oven life is ensured by a ferritic stainless steel interior
The external construction is of mild steel section clad with zinc coated steel sheet
High thermal efficiency is achieved through the use of low thermal mass insulation
Air circulation is critical for efficient and uniform heating and horizontal air flow is achieved via heavy duty impellers at 1400rpm driven by three phase electric motors (vertical airflow is available on selected models if required)
A temperature uniformity of +5°C to within 100mm of the walls and roof and 150mm of the doors and floor is achieved
Most models are fitted with side hinged doors, either single or double, depending on the size of the oven
Vertically rising doors are fitted as standard on large volume 600°C ovens (over 1m3) and are optional on other models
|
|
· Definition : forced convection electric oven for all applications.
· Construction : stainless steel interior, height-adjustable shelf supports.
· Insulation : rock wool insulation of all surfaces, including door.
· Ventilation : stainless steel motor ventilator with adjustable ventilation device.
· Heating : battery of shielded electrical resistors.
· Electricity : Single-phase 230V, 50Hz.
· Regulation : 1 thermocouple with digital temperature controller, programmable timer, RS232 port, safety thermostat.
· Documentation : certification CE and operating instructions in English.
· Delivered with : 2 shelves.
· Versions : *-V models with glass window, otherwise metal door.
|
|
· Definition : forced convection electric oven for all applications.
· Construction : stainless steel interior with shelf supports for a maximum of 4 heightadjustable shelves.
· Insulation : rock wool insulation of all surfaces, including door.
· Ventilation : stainless steel ventilator motor, decoupled from heating for cooling function. Adjustable ventilation.
· Heating : battery of shielded electrical resistors.
· Electricity : 3 x 400V, 50Hz.
· Regulation : 1 thermocouple with digital temperature controller, programmable timer, RS-232 port, safety thermostat.
· Documentation : certification CE and operating instructions in English.
· Delivered with : 2 shelves.
|
|
. Definition : electric, forced air, industrial oven for all industrial applications.
· Construction : monobloc type oven. Interior in aluminium and exterior in galvanised plate.
· Insulation : insulation of all surfaces, including door, using mineral wool and rock wool, floor isolated of 60mm.
· Ventilation : adjustable adjustable horizontal centrifugal ventilation, and adjustable exhaust with top surface outlet.
· Heating : battery of shielded electrical resistors with ventilation exhaust
· Electricity : 3 x 400V power supply, 230V control voltage, 50 Hz frequency
· Regulation : 1 thermocouple, PID digital temperature controller with set and measured display.
· Documentation : certification CE and operating instructions in English.
|
|
· Definition : forced convection electric oven for all applications.
· Construction : stainless steel interior, height-adjustable shelf supports, epoxy-coated exterior.
· Insulation : rock wool insulation of all surfaces, including door.
· Ventilation : stainless steel motor ventilator with adjustable ventilation device.
· Heating : battery of shielded electrical resistors
· Electricity : 3 x 400V, certain models are also available in single-phase 230V-50Hz frequency version.
· Regulation : 1 thermocouple with digital temperature controller, programmable timer, RS-232 port, safety thermostat.
· Documentation : certification CE and operating instructions in English.
· Delivered with : 2 shelves
· Versions : *-M models with single-phase 230V, 400 l volume and up include double door.
|
|
Simtech Flexlam® Laminating Ovens (also called heat boxes) are dedicated to the foil lamination of flat & curved safety, architectural and decorative glass.
To ensure an homogeneous heating, we have designed horizontal air heated electrical ovens. Several available dimensions & heights may meet your requirements. If not, we can design made-to-measure ovens.
We provide the complete solution that includes not only the oven but also the vacuum pump, the trolley, as well as of course series of vacuum rubber bags & connectors.
|
|
The Oven of Air Forced Circulation DYCOMETAL is conceived to can satisfy the present requirements in the matter of Resistance Tests to the Temperature of any element. Its closed air circuit system guaranties a correct stability and uniformity of the temperature allowing a best use of all the compartment with the consequent advantages that this represents.
Its characteristics, guarantee and robustness let it give a high precision and a big functionality to high temperatures with a low cost.
Range of Temperature from Ambient to 200ºC/ 250ºC., and as an Special Oven, it is possible to manufacture to 350ºC/ 400ºC.
Our Ovens,through Kit in option, are ready to can realize Accelerated Old tests BURN-IN or with Artificial Light SUNLAMP (Ultraviolet Radiation Lamps, night/ day Tests, ...).
|
|
· Definition : natural convection electrical oven for all applications.
· Construction : stainless steel interior, height-adjustable shelf supports, with epoxycoated exterior.
· Insulation : rock wool insulation of all surfaces, including door.
· Aeration : aeration device with side-mounted, adjustable, air outlet.
· Heating : battery of shielded electrical resistors.
· Electricity : single-phase 230V, 50Hz.
· Regulation : 1 thermocouple with digital temperature controller, programmable timer, RS-232 port, safety thermostat.
· Documentation : certification CE and operating instructions in English.
· Delivered with : 2 shelves.
|
|
|
The design with vertical, or as shown here with horizontal forced air circulation covers all usual application cases. Batch handling is usually conducted manually or with a feeding cart.
|
|
