Pumpex drainage pumps are submersible to 20 m depth and have no suction lift limitations.
This is superior to any self-priming system due to the fact that the pump is installed submerged in the pit. The pump does not need to be moved with varying water levels and it is designed to run dry in case the water level drops too low.
|
|
APPLICATIONS
* RAIN, SEEPAGE, SUMP PIT AND CATCH TANK WATER PUMP OUT
* GARDEN AND VEGETABLE-GARDEN MINI FLOOD IRRIGATION SYSTEM RAINWATER CATCH TANK PUMP DOWN
* WHITE WATER PUMP OVER FROM RESERVOIRS AND VATS.
* PUMPING DIRTY WATER WITH POSSIBLE FLOATING SOLID CONTENTS (ONLY VOX SERIES)
DESIGN ENGINEERING
* SEMI WET MOTOR WATERCOOLED
* SEALING RING -ENGINE FACE OIL BATH MECHANICAL SEALS
* PERMISSIBLE DRAUGHT OF WATER: 5 m
* IP 68 PROTECTION CLASS.
* CLASS “F” INSULATION.
* MAX. PUMPED LIQUID TEMPERATURE: 50°C
* BY PASS SECTION: 10 mm MIZAR 30/S-60/S
20mm MIZAR 60/S VOX.
|
|
Construction
- Submersible drainage pump constructed with composite polymers developed especially for this product.
- These new rustproof materials are resistant to corrosion, indeformable at maximum temperature differentials in the pump and motor and resistant to internal and external strain.
- Shaft of chrome steel AISI 430. Three lip seals in NBR.
- Minimum dimension and high levels of performance, for flow rates up to 200 liters/min.
- With float switch for automatic start/stop.
Applications
- For clean or slightly dirty water.
- For draining flooded rooms or tanks.
- Extraction of water from ponds, flowing water or pits for collection of rain water.
- For irrigation purposes.
- For use outdoor, the power supply cable shall have a length not less than 10 m.
|
|
Description.
We plan and manufacture high quality submersible electro pump, using the best materials available on the market, Such materials are chosen evaluating the characteristics of the fluid: grey lamellar graphite cast iron …INOX AISI 316 Steel, Duplex, Hasteloy and Marine Bronze. Reliability and duration of Faggiolati products are granted by a perfect balance of the shaft and the impeller and by certified vibration and waterproof resistance test under high reliability.
The product range includes electro pumps which runs from 0.5 Kw to 110 Kw with 2-4-6 poles (50 and 60 Hz) Different type of hydraulic are: Single channel – channels – high efficiency vortex type – drainage – grinder.
Uses
The right type of material is chosen taking in consideration the numerous type of hydraulics , it allow the use of our pump, on salty water and different type of treatment plants as: desalination plant, sewage water raising, pumping and draining of aggressive liquids, industrial waste waters
|
|
The US 75 - 155 series submersible drainage pumps are used for all applications where particularly dirty wastewater with large particle sizes of up to 50 mm need to be pumped. These pumps, with a free passage of 50 mm, pump solids and fibres quickly, reliably and, most importantly, without blockages
- 50 mm free passage
- discharge branch 2"
- Hmax = 13 m
- Qmax = 32 m3/h
|
|
|
|
|
|
FS Series FS-237/337/355/455
Construction Dewatering Pumps
Compact design, high performance and exceptional durability for handling abrasive liquid, widely used on general construction and civil engineering..
Pump Description
Designed for continuous duty with stable operating performance to carry dirty or clean water, for drainage and irrigation purpose. It features an up-discharge and double-casing design and the motor is always cooled by the pumped liquid, which gives it a superior cooling effect and long-lasting running no need to be personally attended on site. The pump is constructed of:
a.fine casting discharge outlet and top cover,
b.rigid stainless steel outer case and strainer,
c.quality stainless steel 410 motor shaft protected by sleeve against
direct wear by the contact parts,
d.double mechanical seals (lower silicon carbide V silicon carbide,
upper carbon/ceramic) in oil chamber,
e.dynamically balanced high chrome steel impeller,
f.lubricated-for-life and maintenance free bearings to support shaft,
g.and standard 10 meters (33 ft) power cord (or longer upon request)
|
|
