The AD7011-EVA is a real time industrial PC equipped with multiple I/Os that can interface with a variety of external devices. It can be used in a wide range of applications as a controller, simulator, real time data logger, or real time data analyzer.
The AD7011-EVA has the following main features.
1) Real time capability and compatibility with RT-Linux (Xenomai).
2) Support for various types of I/O (AD/DA, Ethernet, GPIO, USB, etc.) for
interfacing with a wide range of external devices and systems.
3) An excellent standalone interface via an LCD touch screen and function
keys.
4) A flexible GUI building tool (AD-VirtualConsole) to create user specific
GUIs.
5) The ability to execute MATLAB/Simulink models at the system, which
enables Simulink model execution on real hardware.
6) A C-code programming environment using Eclipse, free software for C
code developers.
The AD7011-EVA is equipped with packaged hardware and the required software, including S-function device drivers for all I/O, a GUI builder (AD-VirtualConsole), and a software development tool (Eclipse), and a demo license for MATLAB/Simulink can be downloaded from The Math Works website. Users can start creating applications almost immediately.
The main board of the AD7011-EVA is equipped with a Freescale i.MX31 CPU with an ARM11 core, 128 MB of DDR SDRAM, 16 MB of NOR Flash for the OS and a 512 MB microSD card for applications.
The AD7011-EVA is excellent support tool for development.
|
|
|
Advantech offers complete fanless Box PCs with rugged, cableless designs for harsh industrial environments. With compact and rich IO, multiple expansion solutions and multiple mounting methods, these platforms are suitable for a wide variety of applications in a wide range of environments. The UNO-1000 series are DIN-rail, fanless BOX PCs, the UNO-1100 series are DIN-rail, high performance fanless BOX PCs, the UNO-2000 series are compact, embedded fanless BOX PCs with PC/104 extensions, the UNO-2100 series are high performance fanless BOX PCs with PC/104 extensions, the UNO-3000 series are front access, high performance fanless BOX PCs with PCI extensions , and the UNO-4000 series are Rackmountable, fanless BOX PCs with PCI extensions.
|
|
The EM-F343 is based on the Intel Celeron M Processor and the Mobile Intel 910GMLE Express chipset. Its robust fanless design makes the EM-F343 an ideal platform for video applications such as digital signs, outdoor advertising, POS systems, information kiosks and embedded gaming computers. It comes equipped with a wide variety of standard computer outputs including S-Video and VGA out video interfaces, Com port, LAN and six USB 2.0 ports for administration and software input, and SATA II and CompactFlash support for storage. The onboard 600/1000MHz Intel Celeron M processor couples low power consumption with minimal cooling requirements, resulting in improved stability and longevity and allowing for completely fanless computer design.
http://www.lannerinc.com/EM-F343
|
|
Worlds First Industrial 9-port Intelligent PoE Routing computer
* Intel IXP430/435 667MHz networking processor
* Complete Layer3 routing support: OSPF, RIP, DVMRP, IPv6
* 8-port PoE delivers full 15.4W per port, 123w per unit
* Full management features with QoS, VLAN, PoE scheduling
* Separated two DC 12~48V power inputs (48V for PoE)
* Versatile interfaces of USB, DIO, SDIO control, and optional modules for RFID, WLAN, and WiMax
* Embedded Linux UIModulized Webmin, capable of running
customized control programs
* Cross-platform applications by JavaVM
* Fan-less and Ruggedized Industrial Design for anti-vibration,
anti-shock, and -25~70oC operation temperature
(-40~80oC for Wide temperature)
|
|
Designed for simple measuring applications up to 16 sensors/measurements and basic statistic analysis, Merlin represents a new concept of gage computer using the same technologies created for PDA and portable electronics, for data collection from traditional or wireless measuring devices.
Embedded technology allows: small dimensions (the whole system footprint is smaller than an A4 sheet of paper), fanless architecture and no moving parts (flash disk storage media), assuring the highest level of system reliability.
Merlin gage software based on Microsoft Windows CE 5.0 guarantees a friendly and easy to use operator interface. Its touch-screen designed human interface allows to program and acquire measures without any additional input/command device.
|
|
|
Nematron is offering a complete range of Embedded Systems and Panels designed specifically for challenging applications. The Embedded ES and Embedded Formula panels are an excellent choice for this. The ES range starts with a very tiny footprint using a 133MHz CPU (ES8020FL) and ends with the high range full blown 2.0 GHz Core 2 Duo CPUs like the ES5630FL. Almost all combinations of CPU power, Chipsets, RS-232/422/485 ports, many USB ports, Ethernet ports, LVDS, DVI, and other common I/O ports can be found on the many units the whole range offers. Several storage capabilities are available to implement. The wide range of Embedded Formula Panels is starting with Xscale CPU Power and goes up to the same high CPU level as the ES series. Screen sizes starting at 8 towards the big 19 displays are available with many different I/O ports and PCI slots if needed. To help you to choose the best possible fit for your application contact Nematron for assistance. www.nematron.net
|
|
|
SMART embedded computer using a unique fanless design, greatly reducing power consumption and fan noise generated, compact appearance of the structure of similar products to overcome the size limitations, can be adapted to different installation requirements, and able to withstand vibration operating environment, such as poor. SMART support high performance Intel Core2 Duo processor, ultra-low power, high performance and low power consumption of both. At the same time, support VGA / DVI display mode, to maximize the flexibility provided.
|
|
Protech introduces modular IPC with powerful CPU, easy maintenance and versatile mounting
Accelerating the integration and deployment of high-performance embedded PCs for a wide range of industrial applications, Protech Systems Co., Ltd., the leading provider of industrial computers, recently launched the EPC-5500 and EPC-5510 modular IPCs featuring support for socket 478 Intel Pentium M/Celeron M Ultra Low Voltage processors with 400 MHz Front Side Bus and up to 2 GB of system memory using DDR333 MHz DIMMs. The EPC-5500/5510 comes with the Intel 855GME/852GM chipset and offers a comprehensive array of I/O interfaces including four serial communication ports supporting RS232/422/485, four high-speed USB 2.0 ports, a 10/100 BASE-T Ethernet port and Gigabit LAN.
Designed for superior peripheral connectivity and data communications, the EPC-5500/5510 is equipped with a 200W AC power supply to provide a versatile and dependable platform for interactive kiosks and manufacturing automation.
|
|
|
|
|
|
Introduction
Moxa UC-8400 series embedded computers use the Intel XScale IXP435 533 MHz RISC CPU. All models are equipped with 8 RS-232/422/485 serial ports, 3 Ethernet ports, 4+4 DI/DO channels, a CompactFlash socket, 2 USB 2.0 hosts, and a PCI-104 bus for flexible expansion. The UC-8416 is equipped with 8 10/100 Mbps Ethernet switch ports and the UC-8418 features 2 CANbus ports. The built-in 16 MB NOR Flash, 32 MB NAND Flash ROM, and 256 MB DDR2 SDRAM provide enough memory to run application software directly on the UC-8400 series for data storage. Moreover, the 256 KB of backup SRAM offers improved data retention for avoiding data loss. All UC-8400 series embedded computers have passed FCC Class B certification.
Features
Customized expansion for greater versatility
Built-in PCI-104 bus for flexible expansion
Multiple connection options
3 10/100 Mbps Ethernet ports for network redundancy
8 RS-232/422/485 serial ports (50 bps to 921.6 Kbps wide baud rate)
4 to 12 DI and DO channels
2 CANbus ports
8 Ethernet switch ports
Intel XScale IXP435, 533 MHz processor
Built-in 256 MB DDR2 SDRAM faster memory read/write
16 MB NOR Flash onboard to store OS, 32 MB NAND Flash onboard for data storage
2 USB 2.0 hosts for mass storage devices
CompactFlash socket for storage expansion
Fanless, cableless, no hard disk, and low power consumption design
Suitable for various applications
256 KB battery backup SRAM
-40 to 75C wide temperature model available
FCC Class B certification
Various storage expansion options, including CompactFlash socket
DIN-rail or wall mounting installation
Linux platform pre-installed
|
|
|
|
|
|
Introduction
The DA-681 computer is based on the Intel x86 processor and supports VGA, 6 Ethernet ports, 4 RS-232 and 8 RS-485 serial ports with optical isolation, CompactFlash, and USB.
The DA-681 is suitable for industrial automation applications that require standard 19-inch rackmount solutions, such as power automation, transportation, and oil and gas. Another plus is that the serial ports come with 2 KV optical isolation protection to guarantee communication reliability in harsh industrial environments.
In addition, the DPP-T models have been certified to meet the IEC 61850-3 standard, making them ideal for power substation automation systems.
The DA-681 runs Linux, WinCE 6.0, or Windows XP Embedded (pre-installed), providing a friendly environment for developing sophisticated application software. The great software support that Moxa provides makes the programmers job easier, and helps programmers develop bug-free code quickly and at a lower cost.
Features
IEC 61850-3 certified for power substation automation systems (DPP-T models only)
Intel Celeron M 1 GHz processor with 400 MHz FSB
1 x 200-pin DDR2 SODIMM socket, supporting DDR2 400 up to 1 GB (512 MB built-in)
Six 10/100 Mbps Ethernet ports
1 CompactFlash socket, 1 IDE and serial ATA-150 connectors for storage expansion
USB 2.0 ports for high speed peripherals
4 isolated RS-232 and 8 isolated RS-485 ports
Serial port speed from 50 to 921.6 Kbps, supporting nonstandard baudrates
Embedded Linux, WinCE 6.0, or WinXPe platform
19-inch rackmount model, 1U height
Dual 100/240 VAC/VDC power input (Single power and dual power models available)
Fanless design
|
|
|
|
|
|
The W406 is an embedded Linux or WinCE computer that features 2 software selectable RS-232/422/485 ports, 1 Ethernet port, and quad-band GSM/GPRS/EDGE 900/1800/850/1900 MHz for cellular communications. It also comes with an SD socket, USB host, and 4 digital input and 4 digital output channels, making it the ideal computer for a variety of industrial applications such as data acquisition, data processing, protocol conversion, and remote device control and monitoring via wireless communications. The W406 comes pre-installed with either Linux or WinCE 6.0, and offers a reliable and powerful computing platform for industrial environments. Programmers will find that the W406 provides a convenient programming environment for producing bug-free industrial applications at a lower cost.
Features
Cirrus Logic EP9302 32-bit ARM9 processor
On-board 32 MB RAM
Built-in 16 MB Flash
Built-in GSM/GPRS/EDGE cellular communication
GSM 850/900/1800/1900 MHz supported
GPRS/EDGE Class 12 supported
SMS tunnel mode provided
4 DIs, 4 DOs
Two software selectable RS-232/422/485 serial ports
50 bps to 921.6 Kbps, non-standard baudrates supported
10/100M Ethernet for network redundancy
SD socket for storage expansion
WinCE 6.0 or Linux 2.6 platform
Din-Rail and Wall mount installation
Robust, fanless design
|
|
This computer utilizes the same components as the paneLink systems and offers similar flexibility in configuration. There are two versions available: the ITXbrick is a simple "brick" computer while the ITXblock has the same components with 2 PCI slots. The family comes in many different configurations. These systems provide solutions for the networked industrial environment in a number of ways: providing simple browser access to a web server, acting as a client in a thin-client architecture, offering the latest embedded operating system or acting as a full fledged industrial computer.
* ITXbrick/block-PXE Thin-Client
* ITXbrick/block-EmbeddedXP
* ITXbrick/block-CE.net
* ITXbrick/block-PC
|
|
Micro Technic designs and manufacturers a range of embedded PC products for industrial and automotive applications:
- Embedded PCs with integrated GPRS/GSM modems
- DIN-rail PCs with expandable I/O for machine control applications and remote telemetry data logging
- Industrial blackbox PC systems for OEMs and machine builders
|
|
Processor Onboard Intel Atom Z510/Z530
Chipset Intel poulsbo SCH
Memory 1x 200-pin SO-DIMM, DDRII 400/533 MHz up to 1GB
Display Intergraded in Intel Poulsbo SCH, share system memory up to 256MB
VGA+S-Video interface
Ethernet/Wireless LAN REALTEK 8111C,10/100/1000Mbps,1x RJ-45, 1x WiFi
Audio 1x Mic-in, 1x line-in
I/O Interface 4x USB2.0, 1 x typeU Compact Flash, 1x SD
EMC CE/FCC Class B
Anti-shock/Vibration 0.5g rms/5~500Hz/Random
Watchdog Timer Generates a time-out system reset
Power Supply DC 12V
Dimensions 120 mm~120 mm~40 mm (W~D~H)
Operating Temperature/Humidity -10`50/5%`95%, 40 Non-condensing
|
|
|
|
|
|
The Relio R1100 delivers the processing power of a desktop computer, yet is small enough to be mounted virtually anywhere. The system is housed in a compact, rugged metal enclosure with the same footprint as Sealevel SeaI/O modules. Powered by a 600MHz ULV Intel Celeron M CPU, the R1100 system offers ultra low power consumption and operates over a wide temperature range. Standard I/O features include 10/100BaseT Ethernet, USB, video, and two serial ports. The R1100 is powered from your 9-30VDC source, or select from a variety of Sealevel power supply options.
The R1100 can operate from CompactFlash and is supported by either XP Embedded or embedded Linux operating systems. For applications that require disk storage, order one of the high-temperature hard drive options listed below. Optional brackets allow for versatile mounting to walls, under counters, on tabletops, or even to DIN rails.
Local or remote I/O expansion is available using Sealevel SeaI/O modules. Choose from a variety of I/O configurations including optically isolated inputs, Reed and Form C relay outputs, TTL interfaces, A/D, and D/A. The unit connects to SeaI/O modules via the system's RJ45 port and communicates using RS-485 Modbus RTU.
|
|
