Kappa introduces a new vision camera based on our modular high-performance platform with 14-bit digitization. The first model, the Zelos-02150 has a GigE Vision interface and offers a resolution of 1920 x 1080p and a frame rate of up to 30 fps. It fulfills all typical Kappa quality characteristics regarding hardiness and longevity.
The camera features several technical highlights. One of them is the 2/3” Kodak sensor KAI-02150, which supports 1080p and excels with an excellent dynamic range and the best image performance. A further plus is the high-performance GigE Vision interface. This creates a perfect combination of a high transfer rate (1 Gbit/s), a low-priced interface on the PC, inexpensive cabling with thin CAT5e cables up to 100 m (300 feet) and a standardized user-friendly communication protocol. The brilliant visualization of the smallest details with the lowest-contrast is the result of the numerous real-time signal processing functions based on a 14-bit digitization. Among the functions are adjustments of different exposure modes, read-out modes (e.g., binning, partial scan), frame rates, gain and exposure settings, measuring window functions, contrast and edge enhancement functions (e.g., histogram equalization), line and circular line generators and dynamic look-up tables. The color processing offers adjustments for the Bayer filter interpolation, color space transformation and color saturation. The modular camera platform can serve different sensors and signal interfaces and thus can fulfill the requirements for machine vision applications as well as applications in defense, aviation and medical imaging.
|
|
|
|
|
|
|
Kappa has successfully extended its camera range with Gigabit Ethernet cameras. The GigE CCD cameras allow cable lengths of up to 100m/330ft (CAT5E) and are available with various sensors; in color, monochrome or cooled versions, with megapixel resolution, frame rates of up to 30/90 Fps and „short trigger delay“ (6,75 micro sec.). The Kappa Software Pool offers three different tools: The camera control software KCC, the software development kit (sdk3) for integration into third-party software interfaces, and the application software KIB for standard measurement tasks. Special Kappa features like the camera-internal color processing and the camera-internal signature creation are also available for the GigE camera model range. The Gigabit Ethernet cameras are equipped with the Gigabit Ethernet interface GigE. There is no need for specific interface cards or expensive and complicated frame grabbers. Kappa Gigabit Ethernet Cameras are compatible with standard Gigabit Ethernet hardware. Bit rates of up to 1 Gbit/s are possible. Economic cables can be used (CAT 5e / CAT 6). GigE Vision enables cable lengths of up to 100 m. Progressive scan CCD, true color quality, megapixel resolution, excellent image quality, 12 bit digitization depth and user-friendly software environment characterize the Gigabit Ethernet cameras. The customer can choose between 2/3, 1/1.8 and 1/2” CCD sensors, color or monochrome. The brilliant high fidelity color reproduction is achieved by the camera-internal Kappa color processing in real-time. Gigabit Ethernet cameras are perfect for multiple camera configurations.
|
|
|
|
|
|
GigE Vision™ is a new camera interface standard developed using the Gigabit Ethernet communication protocol. GigE Vision™ is the first standard to allow for fast image transfer using low cost standard cables over very long lengths. With GigE Vision™, hardware and software from different vendors can interoperate seamlessly over GigE connections.
The standard was developed for industry, by a talented group of companies representing every sector of the vision industry. The Automated Imaging Association (AIA) oversees the ongoing development and administration of the standard.
GigE Vision™ offers many benefits including:
- High bandwidth (1000 Mbps) allows large uncompressed images to be - transferred quickly in real time
- Uncompromised data transfer up to 100 meters in length
- Standard gigabit Ethernet hardware allows single/multiple camera connection to single/multiple computers
- Low cost cables (CAT5e or CAT6) and standard connectors
- Highly scalable to follow the growth of Ethernet bandwidth. As 10GigE becomes mainstream, GigE Vision™ will be the fastest connection in the industry
- Standard hardware, cables allow easy, low cost integration
|
|
GigE uEye SE Industrial Cameras
The GigE uEye® SE extends the broad range of uEye® industrial cameras by very compact models with Gigabit Ethernet interface, specially tailored to the needs of plant and machinery manufacturers.
High-quality CCD and CMOS sensors with resolutions from VGA to 5 Megapixels make way for a wide range of applications.
The GigE uEye® SE models are not only driver compatible with all cameras of the uEye® range and across all interfaces, but also use the same SDK. The outcome is a camera that integrates into existing environments without any changes required.
In addition the uEye® SE provides the same plug-and-play ease for which IDS cameras are widely appreciated: Even Gigabit Ethernet models are configured automatically and are ready for use immediately.
GigE uEye UI-6210SE industrial camera models, VGA (640x480)
- 1/2" CCD sensor, global shutter, progressive scan
- max. 75 fps; 122 fps in AOI-mode with 320x240 pixels
- Exposure: 40 µs - 630 ms (freerun mode)
|
|
|
|
|
|
The cameras ship in robust industrial casing with a C/CS lens mount and optionally with a trigger and digital I/Os. The color, monochrome and Bayer models are available in VGA, XGA and SXGA resolutions.
The software support of the cameras leaves nothing to be desired: Both programmers and end-users immediately feel at home. Getting started with the cameras is a matter of minutes and integrating them into existing applications takes only a few lines of code. Drivers for "LabView", "Halcon", "DirectX", "Twain" and "WDM" are included. All camera parameters and settings can be set via the shipped software. Furthermore, a number of automatic modes are available, which guarantee optimal image quality in varying light conditions.
The cameras ship with drivers for Windows XP/Visa, the SDK "IC Imaging Control" and "IC Capture". The latter is a powerful end-user application, which allows all cameras parameters to be set, live video to be displayed, singular images and image sequences to be captured.
|
|
GE-Series
Compact, high-performance Gigabit Ethernet CCD and CMOS cameras. GigE Vision compliant. Long cable-length, fast frame rates, advanced features.
GC-Series
Ultra compact gigabit Ethernet cameras (GigE Vision). Probably the fastest, and smallest high performance Gigabit Ethernet cameras in the world!
|
|
|
MATRIX VISION's mvBlueCOUGAR-P is a compact industrial Gigabit Ethernet camera with a powerful PowerPC processor. The processor makes sure that the image processing takes place at the sensor directly and only the relevant data are transferred. Consequently bandwidth is saved allowing cameras with higher resolutions and frame rates to be used. Furthermore a processing server no longer has to perform low level processing actions. For this reason, the mvBlueCOUGAR-P is suited mainly to applications in the security industry or for industrial inspection, where a multitude of cameras is used and a large amount of data are processed.
|
|
|
GigE Vision is, in theory, a highly attractive option as a bus standard for implementing machine vision systems. It offers high specifications for data rate and interconnection length, promises interoperability between vendors, and is based on a familiar, mainstream technology with all the concomitant advantages of economies of scale and ubiquity of deployment.
|
|
|
|
|
|
|
The camera series of high-resolution digital cameras is based on variable camera electronics, low power consumption, advanced circuitry, and an extremely rugged design with an excellent signal quality at the same time. The integrator can choose between color or black-and-white systems, high-quality CCD sensors by Sony and Kodak with megapixel resolution and various interfaces (FireWire/ IIDC compatible, CameraLink, GigE). The digital PS cameras have been designed especially for software integrations. The matching Kappa sdk3 offers state-of-the-art software environment based on .net and C-API. Together with the sdk or the detailed interface description the PS cameras convince as high-performance components in all measuring and testing machines.Kappa provides machine vision cameras with top-quality Sony sensors or with Kodak sensors with high refresh rate and square pixel matrix. The machine vision cameras offer highly linear, low-noise signal processing in real time. There is a wide choice of interfaces: RS 422, FireWire, CameraLink, Gigabit Ethernet, USB, HD-SDI, LVDS, video etc... The machine vision cameras from Kappa offer high frame rates and megapixel resolution. With 12 bit digitization depth, raw data and a parametrizable signal processing the machine vision cameras provide numerous measurement advantages. The machine vision cameras are compatible with common image processing software solutions. Machine vision cameras are designed for integration into machines and systems.
|
|
