Kappa introduces a new vision camera based on our modular high-performance platform with 14-bit digitization. The first model, the Zelos-02150 has a GigE Vision interface and offers a resolution of 1920 x 1080p and a frame rate of up to 30 fps. It fulfills all typical Kappa quality characteristics regarding hardiness and longevity.
The camera features several technical highlights. One of them is the 2/3” Kodak sensor KAI-02150, which supports 1080p and excels with an excellent dynamic range and the best image performance. A further plus is the high-performance GigE Vision interface. This creates a perfect combination of a high transfer rate (1 Gbit/s), a low-priced interface on the PC, inexpensive cabling with thin CAT5e cables up to 100 m (300 feet) and a standardized user-friendly communication protocol. The brilliant visualization of the smallest details with the lowest-contrast is the result of the numerous real-time signal processing functions based on a 14-bit digitization. Among the functions are adjustments of different exposure modes, read-out modes (e.g., binning, partial scan), frame rates, gain and exposure settings, measuring window functions, contrast and edge enhancement functions (e.g., histogram equalization), line and circular line generators and dynamic look-up tables. The color processing offers adjustments for the Bayer filter interpolation, color space transformation and color saturation. The modular camera platform can serve different sensors and signal interfaces and thus can fulfill the requirements for machine vision applications as well as applications in defense, aviation and medical imaging.
|
|
GE-Series
Compact, high-performance Gigabit Ethernet CCD and CMOS cameras. GigE Vision compliant. Long cable-length, fast frame rates, advanced features.
GC-Series
Ultra compact gigabit Ethernet cameras (GigE Vision). Probably the fastest, and smallest high performance Gigabit Ethernet cameras in the world!
|
|
|
MATRIX VISION's mvBlueCOUGAR-P is a compact industrial Gigabit Ethernet camera with a powerful PowerPC processor. The processor makes sure that the image processing takes place at the sensor directly and only the relevant data are transferred. Consequently bandwidth is saved allowing cameras with higher resolutions and frame rates to be used. Furthermore a processing server no longer has to perform low level processing actions. For this reason, the mvBlueCOUGAR-P is suited mainly to applications in the security industry or for industrial inspection, where a multitude of cameras is used and a large amount of data are processed.
|
|
|
|
