Industrial gas cylinder LASAL™ 4

helium

DESCRIPTION
LASAL™ is Air Liquide's brand dedicated to laser applications. LASAL™ 4 is a helium lasing gas intended for CO2 laser cavity generation and for welding and cutting laser processes. A CO2 laser with an integrated mixer uses lasing gases (N2, He, CO2); the purity of these gases is critical for source reliability, optical system lifetime, and stability and optimisation of delivered power.

Applications

• Laser cavity gas

Benefits offered by LASAL™ 4

• Productivity
  Supports optimisation of machine productivity, helps reduce operating and maintenance costs, and extends laser lifetime.
• Quality
  Formulated to ensure process safety and consistent laser performance.
• Expertise
  Technical support to define the most suitable gas according to material, application and laser source technology.

Supply modes
LASAL™ 4 (helium lasing gas) is available in individual cylinders and 9-cylinder bundles.

Technical characteristics / specifications

• Reference: I6520
• Commercial name: LASAL™ 4
• Physical state: gaseous
• Relative density (gas): 0.14 (air = 1)
• Relative density (liquid): N/A (water = 1)
• Molecular weight: 4 g/mol
• Valve connection: AFNOR C (21.7 x 1.814 SI - right-hand male). Bundle connector: 38x2 (S)
• CAS No.: 7440-59-7
• Composition: Single molecule - He ≥ 99.996%
• Impurities: H2O (5 bar) ≤ 5; CnHm ≤ 1 (see technical datasheet for full details)
• Colour: colourless
• Odour: odourless
• Hazards: contains gas under pressure; may explode if heated. Asphyxiant at high concentration. Non-flammable.
• Transport: Official designation: Compressed gas cylinders; UN No.: 1046; ADR class: 2; Classification code: 1A
