Industrial gas cylinder LASAL™ 66

gasnitrogenCO2

Description
LASAL is the Air Liquide brand dedicated to laser applications. LASAL™ 66 is formulated for use as a laser cavity gas in CO2 laser systems.

Applications :

• Laser cavity gas for CO2 lasers

Safety & Transport
Hazards: Contains gas under pressure; may rupture if heated. Acts as an asphyxiant at high concentrations.
Flammability range: Non-flammable

Characteristics / Technical specifications

• Reference: I6636L50R2A001
• Variation name: LASAL 66 Cylinder 50L 200 bar
• Pressure: 200 bar
• Packaging type and size: 50L
• Cap: Standard
• Capacity: 8.9 m³
• Physical state: Gaseous
• Relative density (gas): Lighter than air
• Valve connection: AFNOR C (21.7 x 1.814 SI - right-hand male)
• Single molecule: MIX
• Components ( % Vol. abs ): He
  CO2 5% ± 0.25%
  N2 35% ± 1.75%
• Impurities (see product data sheet for full details): H2O (5 bar) ≤ 5
  CnHm ≤ 1
• Color: Colorless
• Odor: Odorless
• Transport - Proper shipping name: Compressed gas
• Transport - UN number: 1956
• Transport - ADR class: 2
• Transport - Classification code: 1A
