Industrial gas cylinder LASAL™ 78

gasnitrogenCO2

Product name
LASAL™ 78

Subtitle
26% N2 + 4% CO2, He (balance)

Brand
LASAL™ is the Air Liquide brand dedicated to laser applications

Applications

• Laser cavity gas for industrial lasers

Composition and properties
Components (vol. % abs): He; CO2 4% ±0.5%; N2 26% ±1.3%
Impurities: H2O (5 bar) ≤ 5 ; CnHm ≤ 1
Color: colorless
Odor: odorless
Physical state: gaseous
Relative density (gas): lighter than air

Safety
Hazards: Contains gas under pressure; may explode if heated. Asphyxiant at high concentration. Non-flammable.

Transport
Proper shipping name: Compressed gas
UN number: 1956
ADR class: 2
Classification code: 1A

Technical characteristics / specifications

• Reference: I6660L50R2A001
• Variant name: LASAL 78 cylinder 50 L 200 bar
• Pressure: 200 bar
• Package type and size: 50 L
• Cap: Standard
• Capacity: 9.6 m³
• Physical state: gaseous
• Relative density (gas): lighter than air
• Valve connection: AFNOR C (21.7 x 1.814 SI - right-hand male)
• Single molecule: MIX
• Components (vol. % abs): He; CO2 4% ±0.5%; N2 26% ±1.3%
• Impurities: H2O (5 bar) ≤ 5 ; CnHm ≤ 1
• Color: colorless
• Odor: odorless
