Industrial gas cylinder LASAL™ 43

gas

Description
LASAL is the Air Liquide brand dedicated to laser applications.

Applications

• Cavity gas for CO2 lasers

Summary
Main composition displayed: 27% N2 + 5.4% CO2 (balance He). Product supplied in 50 L cylinder, 200 bar.

SAFETY
Hazards: Contains a gas under pressure; may explode if heated. Asphyxiant at high concentrations. Flammability range: non-flammable.

TRANSPORT
Official designation: Compressed gas
UN No.: 1956
ADR class: 2
Classification code: 1A

Technical data sheet and safety data
Technical documents and the safety data sheet are available for this product (see the technical data sheet for full details of impurities and characteristics).

Technical characteristics / specifications

• Reference: I6575L50R2A001
• Variant name: LASAL 43 Cylinder 50 L 200 bar
• Pressure: 200 bar
• Packaging type and size: 50 L
• Cap: Standard
• Capacity: 9.3 m³
• Physical state: gaseous
• Relative density (gas): Lighter than air
• Valve connection: AFNOR C (21.7 x 1.814 SI - right-hand male)
• Single molecule: MIX
• Components (% vol. abs): He; CO2 5.4% ±0.11%; N2 27% ±0.54%
• Impurities (see technical data sheet for full details): H2O (5 bar) ≤ 5; CnHm ≤ 1
• Color: colorless
• Odor: odorless
