Industrial gas cylinder LASAL™ 105

gasnitrogenCO2

Description
LASAL is Air Liquide's brand for laser applications. LASAL™ 105 is a pre-mixed gas for use in CO2 laser cavities, supplied in a 50 L cylinder at 200 bar.

Applications

• Cavity gas for CO2 lasers

Composition

• N2 (nitrogen)
• CO: 4 % ± 0.2 % (carbon monoxide)
• CO2: 8 % ± 0.5 % (carbon dioxide)
• He: 28 % ± 0.5 % (helium)

Safety and transport
Hazards: May cause skin irritation. Flammability range: non-flammable.
Official transport designation: Compressed gas cylinders. UN number: 1956. ADR class: 2. Classification code: 1A.

Characteristics / technical specifications

• Reference: I6712L50R2A001
• Variant name: LASAL 105 Cylinder 50L 200 bar
• Pressure: 200 bar
• Package type and size: 50 L
• Cap: Standard
• Capacity: 9.3 m³
• Physical state: Gaseous
• Relative density (gas): Lighter than air
• Valve connection: AFNOR C (21.7 × 1.814 SI - right-hand male)
• Single molecule: MIX
• Components (% vol. abs): N2; CO 4 % ±0.2 %; CO2 8 % ±0.5 %; He 28 % ±0.5 %
• Impurities (see technical data sheet for details): H2O (5 bar) ≤ 5; CnHm ≤ 1
• Colour: Colourless
• Odour: Odourless
