Industrial gas cylinder LASAL™ 83

gasnitrogenCO2

Overview
LASAL is Air Liquide's brand dedicated to laser applications. 40% He + 5% CO2 / N2

Applications

• Cavity gas for CO2 lasers

Safety & Transport
Hazards: Contains gas under pressure; may burst if heated. Asphyxiant at high concentrations. Flammability range: non-flammable.
Transport: Proper shipping name: Compressed gas cylinders. UN No.: 1956. ADR class: 2. Classification code: 1A. ADR pictograms indicated according to regulations.

Sheets & documents
Product data sheet available (see associated technical document). Safety data sheet available.

Characteristics / technical specifications

• Reference: I6680L50R2A001
• Variation name: LASAL 83 Bottle 50L 200 bar
• Pressure: 200 bar
• Type and size of packaging: 50L
• Cap: Standard
• Capacity: 9.9 m³
• Physical state: gaseous
• Relative density (gas): Lighter than air
• Valve connection: AFNOR C (21.7 x 1.814 SI - right male)
• Single molecule: MIX
• Components (% Vol. abs): N2; CO2 5% ±0.25%; He 40% ±2%
• Impurities: H2O (5 bar) ≤ 5; CnHm ≤ 1
• Color: colorless
• Odor: odorless
